1P Flat Single Axis Solar Tracker

Short Description:

ZRP flat single axis solar tracking system has one axis tracking the azimuth angle of the sun. Each set mounting 10 – 60 pieces of solar panels, given a 15% to 30% production gain over fixed-tilt systems on the same size array.


Product Detail

Product Tags

Product Introduction

ZRP flat single axis solar tracking system has one axis tracking the azimuth angle of the sun. Each set mounting 10 – 60 pieces of solar panels, given a 15% to 30% production gain over fixed-tilt systems on the same size array.

At present, the flat single axis solar tracking system in the market mainly has two solar module layout forms, 1P and 2P. Due to the increasing size of solar modules, the length of solar modules has changed from less than 2 meters a few years ago to more than 2.2 meters. Now the solar modules length of most manufacturers is concentrated between 2.2 meters and 2.5 meters. The stability and wind resistance of the flat single axis solar tracking system structure arranged by 2P are greatly challenged, Its long-term system stability needs more practical applications to verify. The single row type 1P layout solution is obviously a more stable and reliable solution.

As a solar tracking system supplier who has been committed to product research and development for many years, we can provide two different mature flat single axis drive solutions: Linear Actuator form and Gear Ring form according to the needs of customers and the actual situation of the project, so as to provide customers with the best solution more flexibly in terms of cost and system reliability.

Product Parameters

System type

Single row type / 2-3 rows linked

Control mode

Time + GPS

Average tracking accuracy

0.1°- 2.0°(adjustable)

Gear motor

24V/1.5A

Output torque

5000 N·M

Tracking power consumption

5kWh/year/set

Azimuth angle tracking range

±45°- ±55°

Back tracking

Yes

Max. wind resistance in horizontal

40 m/s

Max. wind resistance  in operation

24 m/s

Material

Hot-dipped galvanized65μm

System warranty

3 years

Working temperature

 -40- +80

Weight per set

200 – 400 KGS

Total power per set

5kW – 40kW
