25W Attenuator Operating From DC-3GHz,3/6/10/15/20/30dB Available JX-RN-25-XX-3
Description
25W Attenuator Operating From DC-3GHz, 3/6/10/15/20/30dB Available
The 25w coaxial attenuator JX-RN-25-XX-3 is designed by , covering the frequency from DC-3GHz.The attenuation of 3/6/10/15/20/30dB is available for different applications, featuring with VSWR of 1.2, the ripple of In-band around 0.3-1dB. It matches with N connectors, measuring 109mm x∅45mm.
This DC-3GHz RF attenuator has been tested well in the field of the client, more testing detail can be offered for reference. If need custom attenuators, can help you out. As promised, all the RF passive components from have 3 years warranty.
Parameter
| Parameter |
Specification |
|||||
| Frequency range |
DC-3GHz |
|||||
| Attenuation |
3dB |
6dB |
10dB |
15dB |
20dB |
30dB |
| Decay accuracy |
±0.4dB |
±0.4dB |
±0.6dB |
±0.6dB |
±0.8dB |
±0.8dB |
| In-band ripple |
±0.3 dB |
±0.5 dB |
±0.7 dB |
±0.8 dB |
±1.0 dB |
±1.0 dB |
| VSWR |
≤1.2 |
|||||
| Rated Power |
25W |
|||||
| Peak Power |
10KW |
|||||
| Temperature range |
-55 ~ +125ºC |
|||||
| Impedance all ports |
50Ω |
|||||
Custom RF Passive Components
Only 3 Steps to Solve Your Problem of RF Passive Component
1. Defining the parameter by you.
2. Offering the proposal for confirmation by .
3. Producing the prototype for trial by .
