32″ Curved Multi-Touch Gambling Monitor FHD

Short Description:

The MC320265 is a 32″ curved PCAP solution featuring Full HD resolution (1920 x 1080) and 10-point touch technology. With its pure flat structure, LED light bar, and industrial-grade LCD panel, this monitor is both stylish and durable, with excellent water resistance and anti-vandal properties. The monitor’s ultra-fast refresh rate, wide viewing angles, and rich colors make for a truly immersive experience, while its smooth operation and high touch accuracy ensure a superior user experience.

Size: 32 inch Maximum Resolution: 1920*1080 Contrast Ratio: 3000:1 Aspect Ratio: 16:9 Brightness: 250cd/m2 (no touch); 213cd/m2(with touch) View Angle: H:89°/89°, V:89°/89° Video Port: 1 x VGA, 1 x DVI

Send email to us Download as PDF

Product Detail

Product Tags

Featured Specifications

● Size: 32 inch

● Maximum Resolution: 1920*1080

● Contrast Ratio: 3000:1

● Brightness: 250cd/m² (no touch); 213cd/m²(with touch)

● View Angle: H:89°/89°, V:89°/89°

● Video Port:1 x VGA,1 x DVI

● Aspect Ratio: 16: 9

● Type: Open Frame

Specification

Touch LCD Display
Touch Screen	Projected Capacitive
Touch Points	10
Touch Screen Interface	USB (Type B)
I/O Ports
USB Port	1 x USB 2.0 (Type B) for Touch Interface
Video Input	VGA/ DVI
Audio Port	None
Power Input	DC Input
Psical Properties
Power Supply	Output: DC 12V±5% External Power AdaptorInput: 100-240 VAC, 50-60 Hz
Support Colors	16.7M
Response Time (Typ.)	21ms
Frequency (H/V)	54.15~84.38KHz / 49~72Hz
MTBF	≥ 30,000 Hours
Power Consumption	Standby Power: ≤2W; Operating Power: ≤40W
Mount Interface	VESA 200mm
Dimensions (W x H x D) mm	768.4456109.6(mm)
Regular Warranty	1 year
Safety
Certifications	CCC, ETL, FCC, CE, CB, RoHS
Environment
Operating Temperature	0~50°C, 20%~80% RH
Storage Temperature	-20~60°C, 10%~90% RH
