358 security fence anti climb fence panel
Anticlimb Standard Fence Panel
Broadfence’s Anticlimb Standard Fence Panel is strong and durable, yet lightweight and easy to install. These 11’ 4” long and 6’ 7” high fence panels are perfect for large construction sites, enclosing hazards, concert and festival crowd control, event perimeters, environmental control and general road and civil works.
|
Panel-Type A(2D view) |
||||
|
Mesh |
Wire Thickness |
Surface Treatment |
Panel Width |
Height |
|
76.2×12.7mm |
Horizontal wire:3,3.5,4mmVertical wire:4mm | Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
2.5m or 2.2m |
1800mm |
|
2000mm |
||||
|
2100mm |
||||
|
2200mm |
||||
|
2400mm |
||||
|
2500mm |
||||
|
3000mm |
||||
|
Weld strength:-75% of the minimum tensile strength of the wire;Tensile range 540-690 N/m² |
||||
|
Panel-Type B(3D View) |
||||||||||
|
Mesh |
Wire Thickness |
Surface Treatment |
Folds Nos |
Panel Width |
Height |
|||||
|
76.2×12.7mm |
Horizontal wire:3,3.5,4mmVertical wire:4mm | Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
3 |
2.5m or 2.2m |
1800mm |
|||||
|
3 |
2000mm |
|||||||||
|
4 |
2100mm |
|||||||||
|
4 |
2200mm |
|||||||||
|
4 |
2400mm |
|||||||||
|
5 |
2500mm |
|||||||||
|
6 |
3000mm |
|||||||||
| Weld strength:-75% of the minimum tensile strength of the wire;Tensile range 540-690 N/m² | ||||||||||
|
Panel-Type C(2D View,adding wire) |
||||||||||
|
Mesh |
Wire Thickness |
Surface Treatment |
Panel Width |
Height |
||||||
|
100×15mm |
Horizontal wire:3.5mmVertical wire:5.5mm | Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
2.5m or 2.2m |
1800mm |
||||||
|
2000mm |
||||||||||
|
2100mm |
||||||||||
|
2200mm |
||||||||||
|
2400mm |
||||||||||
|
2500mm |
||||||||||
|
3000mm |
||||||||||
|
With additional horizontal wire of 3.5mm at 18cm intervals |
||||||||||
|
Weld strength:-75% of the minimum tensile strength of the wire;Tensile range 540-690 N/m² |
||||||||||
Applications:
Anti-Climb, safety screening; Sub-station security, hospital security fencing, factory machine guards; Walkway security fencing; Airport security fencing; 358 wire mesh fence gates; shipping port security, etc.
|
Prison fence / airport fence panel specification |
||||
| Panel size | Wire dia | Mesh size | Surface treatment | Folds ( or no folds |
| (height) | as your request) | |||
| 1.03m | 3mm-6mm | Electro GI+PVC coated | 2 | |
| 1.23m | 50x50mm, 50x75mm | Electro GI+ painting(Spraying) | 2 | |
| 1.5m | 50x100mm | Hot-dipped GI only | 2 or 3 | |
| 1.53m | 50x150mm | Hot-dipped GI +PVC coated or painting | 2 or 3 | |
| 1.7m | 50x200mm | 3 | ||
| 1.73m | 55x100mm | 3 | ||
| 1.8m | 75x200mm | 3 or 4 | ||
| 1.93m | 60x150mm | 3 or 4 | ||
| 2.0m | Or as your request | 4 | ||
| 2.03m | 4 | |||
| 2.4m | 4 | |||
|
Specification of fence post |
||
| Post Style | Post Size | Post height |
| Rectangle Post | 40 x 60 x 1.5mm | 1.6m |
| 40 x 60x 2mm | 1.8m | |
| 60 x 80 x 2mm | 2m | |
| Square Post | 40 x 40 x 1.5mm | 2.1m |
| 60 x 60 x 2mm | 2.3m | |
| 80 x 80 x 2.5mm | 2.5m | |
| 100 x 100 x 3mm | 2.8m | |
| Peach post | 50 x 70mm | 3.0m |
| 70 x 100mm | 3.5m | |
| Round post | Φ38 x 1.5mm | 4.0m |
| Φ42 x 2mm | 4.5m | |
| Φ48 x 2mm | ||
| Φ60 x 2.5mm | ||
Features :
Anti-Climb
Protects against cut-through
Increased delay factor
Excellent visibility
Vandal resistant
Compliments CCTV
Versatile
Cost effective
High security fence system is well known in the world as an anti-climb & anti-cut through barrier,while providing the lowest level high quality carbon steel wires.It is designed to give attractive,long lasting and secure perimeter protection for industrial and commercial properties,public utilities,and it is really suited for electronic alarm and detection systems-no blind spots for CCTV.It is also a good choice for Military,airports,secure units and prisons.
Applications:
Anti-Climb, safety screening; Sub-station security, hospital security fencing, factory machine guards; Walkway security fencing; Airport security fencing; 358 wire mesh fence gates; shipping port security, etc.
