3KW All-in-one Solar Inverter

Short Description:

3KW All-in-one Solar Inverter|Get the Manufacturer Price Now

Place Of Origin: Shenzhen, Guangdong Province, China Brand Name: MOQ: 10 set Accept; Customization (at least 10 sets) Payment: T/T, L/C, Western Union

Send email to us Download as PDF

Product Detail

Product Tags

3KW All-in-one Solar Inverter Feature

Stable

Advanced SPWM modulation technology with pure sine wave output and high power quality.

High power density and long life devices are selected to support long term operation at full power.

Efficiency

High conversion effciency,low losses and low harmonic distortion rate.

Multiple operating modes for maximum power savings.

Intelligent

Bluetooth as standard,supports mobile phone app to view device operating parameters.

Multiple expansion interfaces to meet the diverse needs of users.

Safety

With battery over-voltage and over-discharge protection,output overload andshort-circuit protection and over-temperature protection.

(there is no reverse connection protection, please do not reverse the connection)

3KW All-in-one Solar Inverter system Schematic Diagram

3KW All-in-one Solar Inverter Electrical Parameters

ITEM	IC24-3kW
Rated Battery Voltage	24Vdc
Battery Voltage Range	21.6~32Vdc
Rated Output Power	3,000W
Peak Power	6,000W
Rated Output Voltage	220/230(default)/240Vac(±3%)
Output Frequency	50/60Hz
Output Waveform	Pure Sine Wave
THD	THD<4%(Resistive Load)
Power Factor	0.2-1(Load Power≤Continuous Output Power)
Rated Output Efficiency	>90%
Max. Output Efficiency	>93.5%(30% Load)
Standby Current (OFF mode)	<0.12A
0 Load Ourrent (ON mode)	<0.95A
Dimensions	409249120mm
Weight	6.0kg
Noise	<60dB
Cooling Method	Neutral Cooling+ Intelligent Fan
IP Grade	IP20
Ambient Temperature	-20°C~60°C

3KW All-in-one Solar Inverter’s Ports

No.	Type
1	Battery Postive +
2	Battery Negative -
3	Output Overload Protector
4	AC Output Port 1(wiring terminal)
5	AC Output Port 2(socket)
6	RS485 port
7	USB charging port*2 5V/2A
8	ON/OFF/ECO mode switch
9	TTL Port
10	Operating Indicator
11	False Indicator
12	Remote ON/OFF switch port

The Applications of the IC24-3kW Solar Inverter

The IC24-3KW All-in-one inverter is suitable for home appliances, power tools, RVs, boats, and off-grid solar systems.it’s essential for anyone looking to generate their own power.

With its high power output, pure sine wave output waveform, and low THD (total harmonic distortion), the IC24-3kW inverter can be well-suite for a wide range of applications. Its peak power rating of 6KW makes it capable of powering appliances with high starting currents, such as refrigerators and air conditioners.

So, whether you’re a homeowner looking to power your appliances during a blackout, or a camper looking for a reliable source of power on the go, the IC24-3kW inverter is a perfect choice. And with its user-friendly design and easy installation process, you can have it up and running in no time.
