4 STROKE GASOLINE ENGINE FLOAT PUMP FP140
Parameters
| MODEL: | FP140 |
| TYPE: | SELF PRIMING |
| FLOW(m3/h): | 25 |
| LIFT(m): | 12 |
| SUCTION LENGTH(m): | – |
| MATCHED ENGINE: | 140FA |
| DISPLACEMENT(cc): | 37.7 |
| MAX.POWER(kw/r/min): | 1.0/6500 |
| INLET&OUTLET SIZE(mm): | 1″ |
| FUEL TANK CAPACITY(L): | 0.7 |
| NET WEIGHT(kg): | 9.5 |
| PACKAGE(mm): | 610*360*280 |
| LOADING QTY. (1*20 feet) | 455 |
Features
SURGING POWER , NO CYLINDER PULLING
The use of high-strength core piston, crankshaft and magnetic flywheel improves engine performance and significantly increases power output.”
FAST HEAT DISSIPATION
The cylinder adopts three-dimensional circulation heat dissipation, and the distribution of the heat dissipation holes of the cylinder shield is more reasonable, even if the water is pumped day and night, it will not turn off the fire, let alone pull the cylinder
VIBRATION , NOISE REDUCTION
Equipped with a 4-stroke gasoline engine for lower noise when the machine is running.
It adopts shock-absorbing design, and connects the frame with gasoline engine and water pump with shock-absorbing rubber column.
ADJUSTABLE WATER FLOW
With the booster nozzle, the size of the water flow can be adjusted arbitrarily, the spray is farther, and the impact is stronger.
Notice
In order to ensure that you can better use the FP140 water pump, please pay attention to the following points before use:
1: Read the instruction manual carefully
2: Before using the machine, fill the water injection port of the machine, otherwise the suction power of the water pump is insufficient and cannot work normally.
3: Place the boat pump on a wide surface and clean water
4: Try to pump clean water sources, otherwise you may block the water pipe due to debris in the water.
5: This machine is a 4-stroke gasoline engine, please fill the special oil for 4-stroke gasoline engine when using.
6: Fill with pure gasoline above 90# when using.
7: Regularly check whether the screws of each connection part are loose.
