6 Seater Golf Cart for Sale with New Design
Specification
|
Power |
ELECTRIC |
HP ELECTRIC |
|
|
Motor/Engine |
4KW(AC) motor | 5KW(AC) KDS motor | |
|
Horsepower |
5.44hp | 6.67hp | |
|
Batteries |
Six, 8V150AH Battery | 48V 105-50AH Lithium-Ion (1) | |
|
Charger |
48V/25A | 48V/25A | |
|
Max. Speed |
13.7mph(22khp) | 13.7mph(22khp) | |
|
Steering & Suspension |
Steering |
Bidirectional rack and pinion steering system | |
|
Suspension |
Double-arm independent suspension + suspension spring | ||
|
Brakes |
Brakes |
Double-circuit four-wheel hydraulic front disc rear drum brake | |
|
Park Brake |
Electromagnetic parking | ||
|
Body&Tires |
Body&Finish |
Front&Rear: Painted Injection moulding | |
|
Tires |
205/50-10(Tire diameter 18.1in) (460mm) | ||
|
L*W*H |
151.7*47.2*72.9in (3850*1200*1850mm) | ||
|
Wheelbase |
124.9in (3170mm ) | ||
|
Ground Clearance |
4.7in (120mm) | ||
|
Tread-Front and Rear |
Front 34.7in (880mm) ; Rear 39.0in (990mm) | ||
|
Total Vehicle Weight |
1342lbs(610kg)（including batteries）902lbs(410kg)（without batteries） | ||
|
Frame Type |
High strength carbon steel integral frame | ||
Introduction
TOYOTA CONTROLLER
star golf carts have two sets of battery power system for choices , 105-150Ah Lithium ion battery pack support you can spend more time and offer enough golf cart horsepower on the course than, you will feel a longer lifespan, higher power and a higher safety rating than other types of lithium battery options.
BEEFED UP TRANSAXLE
advanced ev golf cart use integral rear axle, it is integrated pressure-die-casting aluminum gearbox housing and tightly sealed, the power is transmitted by mesh and involute teeth bevel gears, you will drive with generate steady output torque, lower noise and better performance.
CURTIS CONTROLLER
6 seater golf cart use Curtis controller as optional function and which model are welcomed in the market, Curtis controller is bundled with Charging protection and Anti Skipping regenerating braking to provide you with more safety redundancy downhill riding.
WATERPROOF WIRING HARNESS
All the electronic components of 6 seater golf cart are used with waterproof wiring harness IP67 and AMP connectors, which prevent water and rainy weather, not easy to get short circuit, reduce the maintenance cost.
All the electronic components of 6 seater golf cart are used with waterproof wiring harness IP67 and AMP connectors, which prevent water and rainy weather, not easy to get short circuit, reduce the maintenance cost.
Features
☑ Combination of style and performance.
☑ Better handling and safety performance.
☑ Excellent hill climbing and parking abilities.
☑ Quick and efficient battery charge maximizes up-time.
☑ With 48V KDS Motor, stable and powerful when going uphill.
Application
Golf carts for sale built for golf courses, hotels and resorts, schools, real estate and communities, airports, villas, railway stations and commercial establishments, etc.
FAQ
6 person golf cart have optional configurations and the cost is upon your need, so contact us and join our team anytime for more.
Sea freight, Air freight are based on your quantity, learn more send enquiry to join our team.
Of course, please send your information and ask our dealers of florida golf cart to contact you.
Yes, welcome to be our golf carts dealers, please check Partnership Policy on Service page or leave the contact, we will call you soon.
For sample and if we have it in stock, 7 days after receiving the payment.
For mass production quantity, one month after receiving the deposit payment.
