6KW E-Gas Hot Water And Warm Air Integrated Heater
6KW E-Gas Hot Water and Warm Air Integrated Heater
1.Application
Heating and hot water in one: NF Combi heaters
NF Combi heaters combine two functions in one appliance. They warm the living area and heat water in the integrated stainless steel tank. Depending on the model, Combi heaters can be used in gas, electric, diesel or mixed mode.Combi D 6 E heats your vehicle and heats water at the same time. Integrated electric heating elements reduce the heating time.
2.Technology data
| Rated Voltage | DC12V |
| Operating Voltage Range | DC10.5V～16V |
| Short-term Maximum Power Consumption | 5.6A |
| Average Power Consumption | 1.3A |
| Gas Heat Power (W) | 200040006000 |
| Fuel Consumption (g/H) | 160 320 480 |
| Gas Pressure | 30mbar |
| Warm Air Delivery Volume m3/H | 287max |
| Water Tank Capacity | 10L |
| Maximum Pressure of Water Pump | 2.8bar |
| Maximum Pressure of System | 4.5bar |
| Rated Electric Supply Voltage | ～220V |
| Electrical Heating Power | 900W 1800W |
| Electrical Power Dissipation | 3.9A7.8A |
| Working (Environment) Temperature | -25℃～+80℃ |
| Working Altitude | ≤1500m |
| Dimensions (mm) | 510×450×300 |
| Weight (Kg) | 15.6Kg |
