Adjustable Aperture 1-12mm Mechanical Iris Camera Microscope Optical Module Diaphragm
A camera iris is the part that controls how much light comes through the lens. With a manual iris, the operator can adjust the opening to allow more or less light by physically adjusting the iris. The light that the iris allows through hits the image sensor and that light gets recorded as electrical impulses that create the video.
In optical experiments, we often need focal light source or control the light. The Unmounted High-Power Adjustable Iris Diaphragms are feasible with continuously adjustable clear aperture.
Application: Optical path testing and optical manufacturing
| Material: | ||
| Part | Material | Surface treent |
| Shell | A6061 | Anodize black |
| Handle | C3604 | Nickel plating |
| Blade | Cr03 | Black anodize with lubrication coatings |
| Rivet | H62 | Anodize black |
| Spring | T2A | Anodize black |
Referenced Drawing:
1) Outside Diameter: 19.8 mm.
2) Inside Diameter: 12 mm.
3) Thickness: 5 mm.
4) Minimum Aperture Diameter: 1 mm.
5) Maximum Aperture Diameter: 12mm.
6) Blades Quantity: 10 pieces.
|
No. |
Aperture(mm) |
Outside diameter(mm) |
Thickness (mm) |
Blades |
Material |
Installation site |
||
|
max |
min |
Inner |
An outer ring (shell) |
|||||
|
1 |
6.8 |
0.5 |
22.5 |
4.5 |
6 |
Copper |
Copper |
Outer |
|
2 |
7.5 |
0.8 |
14 |
5 |
8 |
Copper |
Copper |
Outer |
|
3 |
10 |
1 |
20 |
5 |
9 |
Aluminum |
Aluminum |
Outer |
|
4 |
12 |
1.2 |
19.8 |
5 |
10 |
Aluminum |
Aluminum |
Outer |
|
5 |
14 |
1.2 |
25.5 |
5.5 |
10 |
Aluminum |
Aluminum |
Outer |
|
6 |
18 |
1.2 |
28 |
5 |
12 |
Copper |
Copper |
Outer |
|
7 |
20 |
1 |
45 |
6 |
10 |
Aluminum |
Aluminum |
Side cone snails |
|
8 |
20 |
1 |
45 |
6 |
10 |
Aluminum |
Aluminum |
Thread Desk |
|
9 |
22 |
1.2 |
36 |
6 |
10 |
Aluminum |
Aluminum |
Outer |
|
10 |
28 |
2.5 |
49 |
8 |
12 |
Steel |
Aluminum |
Thread Desk |
|
11 |
28 |
2 |
49 |
8 |
12 |
Steel |
Aluminum |
Thread Desk |
|
12 |
28 |
2 |
49 |
7.5 |
12 |
Steel |
Aluminum |
Outer |
|
13 |
30 |
1.6 |
50.5 |
8 |
12 |
Aluminum |
Aluminum |
Thread Desk |
|
14 |
36 |
1.8 |
50 |
6 |
16 |
Aluminum |
Aluminum |
Outer |
|
15 |
42 |
2.5 |
58 |
6.5 |
18 |
Aluminum |
Aluminum |
Outer |
|
16 |
52 |
3 |
78 |
13 |
14 |
Aluminum |
Aluminum |
Thread Desk |
|
17 |
52 |
3 |
73 |
8.4 |
14 |
Aluminum |
Aluminum |
Outer |
|
18 |
59 |
9 |
78 |
12 |
20 |
Aluminum |
Aluminum |
Outer |
|
19 |
12 |
1 |
20 |
5 |
10 |
Aluminum |
Aluminum |
Outer |
|
20 |
80 |
8.5 |
105 |
12 |
20 |
Aluminum |
Aluminum |
Outer |
