All Pipes 8 Axis Autocad Cnc Plasma Tube Cutting Machine
Product Description
cnc plasma tube cutting machine With high degree of automation and cutting quality.It has the characteristics such as optimizion material, variety of programming and so on.Has the complete range of welding beveling type,with the perfect docking to TEKL A.lt can generate G codedirectly, 3D simulation operation, node expansion, ultra long pipepartition,pipe optimization and other management functions.
Application
1. Applicable to round pipe and rectangular pipe and other square pipe profile production enterprises. 2. Especially suitable for industries such as steel structure, shipbuilding, marine engineering, elevator industry, building curtain wall, bridge tower and construction machinery main parameter
Machine Feature
1. Adopt welding platform, heavy rail and improve the overall bearing weight, human design human-computer exchange more convenient and reasonable, stable operation and increased life expectancy.
2. Independent research development to optimize CNC pipe systems, auto CAD version of the engineering design can generate standard G code directly, three-dimensional simulation of the operation, node expansion, long split pipe, fittings optimization, over sized DXF SAT software compatibility and lifetime free upgrade process can be modified according to user needs
3. Aiwan’s Advantech industrial computer can be programmed directly on the machine. Using menu-select input cutting parameters such as diameter, wall thickness, bevel angle deviation compensation data. By KASRY professional pipe cutting applications for a seamless connection.
Software Advantage
1.Perfectly compatible with Tekla round pipe modelling.
2.Support end hole, slot and bevel cutting.
3.Support Second development of autopipe at AutoCAD.
4.Super high nesting speed and usage rate.
5.Break, Mirror, left&right, G code.Professional nesting software——PipeNest, with optimization function.Support offshore AWS small angle cutting process.
