- One line dual fillers, Main & Assist filling to keep work in high-precision.
- Can-up and horizontal transmitting is controlled by servo and pneumatic system, be more accurate, more speed.
- Servo motor and servo driver control the screw, keep stable and accurate
- Stainless steel structure, Split hopper with polishing inner-out make it to cleaned easily.
- PLC & touch screen make it be easy of operation.
- Fast-respond weighing system make the strongpoint to real
- The handwheel make the exchange of different filings to be easily.
- Dust-collecting cover meet the pipeline and protect environment to pollution.
- Horizontal straight design make the machine in little area
- Settled screw setup make no metal pollution in producing
- Process: can-into → can-up → vibration → filling → vibration → vibration → weighing & tracing → reinforce → weight checking → Can-out
- With whole system central control system.
Model |
SP-W12-D140 |
SP-W12-D210 |
Dosing mode |
Dual filler filling with online weighing |
Dual filler filling with online weighing |
Filling Weight |
100 – 1500g |
100 – 5000g |
Container Size |
Φ60-140mm; H 60-260mm |
Φ60-210mm; H 60-260mm |
Filling Accuracy |
100-500g, ≤±1g; 500-1000g,≤±2g; >1000g, ≤±3-4g |
100-500g, ≤±1g; 500-1000g,≤±2g; >1000g, ≤±3-4g |
Filling Speed |
45 cans/min (#502) |
35 cans/min (#603) |
Power Supply |
3P AC208-415V 50/60Hz |
3P, AC208-415V, 50/60Hz |
Total Power |
3.4 kw |
4.75kw |
Total Weight |
450kg |
650kg |
Air Supply |
0.2cbm/min, 0.6Mpa |
0.2cbm/min, 0.6Mpa |
Overall Dimension |
2650×1075×2683mm |
3200x1170x2920mm |
Hopper Volume |
50L(Main) 11L (Assist) |
75L(Main) 25L (Assist) |
