Bearing Steel GCr15 AISI 52100 100Cr6 and SUJ2 Bearing Round Bar

Short Description:

Name: Bearing Steel GCr15 AISI 52100 100Cr6 and SUJ2 Bearing Round Bar

Type: Cold rolled/hot rolled/Forging

Grade: 1.3505 100Cr6 AISI 52100 Gcr15 SuJ2

Size:  OD10mm-1600mm

Condition:Normalized ; Annealed ; Quenched ; Tempered,Forging

Mill Test Certificate:  EN10204 3.1

Processing: Bending/ Cutting/Polished/Chrome Plated


Product Detail

Product Tags

Product Details

Bearing steel is the steel used to manufacture balls, rollers, and bearing rings. Bearing steel has high and uniform hardness, wear resistance and high Elastic Limit. The requirements for the uniformity of chemical composition, the content and distribution of non-metallic inclusions, and the distribution of carbides in bearing steel are very strict. The bearing material is made of high carbon steel. High carbon steel is often called Tool steel, with carbon content ranging from 0.60% to 1.70%, which can be quenched and tempered. Hammers, crowbars, etc. are made of steel with a carbon content of 0.75%.
The heat treatment process for bearing steel consists of two main steps: pre heat treatment and final heat treatment. GCr15 steel is the most widely used type of bearing steel, a high carbon chromium bearing steel with low alloy content and good performance. GCr15 bearing steel has high and uniform hardness, good wear resistance, and high contact fatigue performance after heat treatment.

Most bearings use SUSJ2, a type of JIS steel, which is domestic chromium steel (GCr15).
The chemical composition of SUJ2 has been standardized as a bearing material in various countries around the world. For example, it belongs to the same type of steel as AISI52100 (USA), 100Cr6 ( Germany), BS535A99 (UK), etc..

Parameters

Size Round Bar OD10mm-1600mm
Plate/Flat/Block bars Thickness6mm-500mm
Width20mm-1000mm
Heat treatment Normalized ; Annealed ; Quenched ; Tempered
Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery condition Forged; Hot rolled; Cold drawn
Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment terms T/T;L/C;/Money gram/ Paypal
Trade terms FOB; CIF; C&F; etc..
Delivery time 30-45 days

Equal Bearing Steel Grade

Country

German

Japan

British

CHN

USA

Standard

DIN 17230

JIS G4805

BS 970

ASTM A295

Grades

100Cr6/1.3505

SUJ2

535A99/EN31

Gcr15

52100

Chemical Composition(%)

Grade

C

Si

Mn

P

S

Cr

Mo

Ni

EN31/535A99

0.95-1.10

0.10-0.35

0.25-0.40

0.04

0.05

1.20-1.60

/

/

52100/1.3505

0.93-1.05

0.15-0.35

0.25-0.45

0.025

0.015

1.35-1.60

0.10

0.30

SUJ2

0.95-1.10

0.15-0.35

0.50

0.025

0.025

1.30-1.60

0.08

0.25

GCr15

0.95-1.05

0.15-0.35

0.25-0.45

0.025

0.025

1.40-1.65

0.10

0.30

Applications

Bearing steel is a type of steel used to manufacture rolling bearings, such as balls, rollers, and sleeves. It can also be used to make precision measuring tools, cold stamping dies, machine tool screws, precision components such as dies, measuring tools, taps, and diesel engine oil pumps. Bearing steel is the steel used to manufacture balls, rollers, and bearing rings.
