Bimetal Thermostat Home Appliance Parts Temperature Switch Defrost Thermostat WR50X10068
Product Parameter
| Use | Temperature control/Overheat protection |
| Reset type | Automatic |
| Base material | Resist heat resin base |
| Electrical Rating | 15A / 125VAC, 10A / 240VAC, 7.5A / 250VAC |
| Max. Operating Temperature | 150°C |
| Min. Operating Temperature | -20°C |
| Tolerance | +/-5°C for open action(Optional +/-3 C or less) |
| Protection class | IP00 |
| Contact material | Double Solid Silver |
| Dielectric Strength | AC 1500V for 1 minute or AC 1800V for 1 second |
| Insulation Resistance | More than 100MΩ at DC 500V by Mega Ohm tester |
| Resistance Between Terminals | Less than 50MΩ |
| Diameter of bimetal disc | Φ12.8mm(1/2″) |
| Approvals | UL/ TUV/ VDE/ CQC |
| Terminal type | Customized |
| Cover/Bracket | Customized |
Applications
- Automotive seat heaters
- Water heaters
- Electric heaters
- Anti freeze sensors
- Blanket heaters
- Medical applications
- Electrical appliance
- Ice makers
- Defrost heaters
- Refrigerated
- Display cases
Features
- High Quality, Easy Installation and Quick Solution
- Durable high quality material
- Well-tested by the manufacturer
- Perfect fit
- Ensure long-lasting
- Fully assembled for easy installation
