Bus Rear Window LED Screen
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Export Standard Plywood Carton |
| Delivery Time: | 3-25 working days after received your payment |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 2000/set/month |
Advantage
1. The LED vehicle rear window screen of the bus is made of: vehicle power supply, vehicle advertising control system, and customized LED unit board materials. It displays text, pictures, animations, and videos through dot matrix lighting.
2. The LED bus rear window advertising screen integrates a 4G module, which can realize the one-to-many control of the advertising publishing platform, so that the advertisements can be updated synchronously from time to time, and the operation is convenient.
3. The display size of the LED display advertising screen on the rear window of the bus can be customized according to the size of the actual bus rear window glass, which can make the advertising display effect better.
4. The product can realize the function of timing advertisements by integrating GPS, and can place advertisements and times of advertisements in designated areas at fixed times, so as to serve media companies more intelligently.
5. The rear window LED display has passed a variety of tests and has the characteristics of anti-static, anti-vibration, high temperature resistance, and moisture resistance.
6. Support 4G and WiFi, with advertisement publishing system and cluster control, and also support secondary development, etc.
7. It is easy to install, and it can be used stably for a long time by fixing the mounting bracket on the rear window platform of the bus.
Bus Rear Window LED Display Product Details
Screen Front
Screen Bottom
High Brightness LED Module
Screen Side
Customized Fixed Brackets
Heat Sink
Screen Top
WiFi Antenna
Screen Backplane
Video Center
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
.yt_video{ width: 100%; aspect-ratio: 374 / 210; max-width: 1920px; margin: 0 auto; } .yt_video iframe {width:100%;height:100%;}
Design for Power Efficiency
The customized power supply module adopts an energy-saving design to keep average power consumption below 80 watts, significantly reducing energy use. This innovative technology improves efficiency and extends the equipment’s service life, providing a more environmentally friendly and economical solution.
High Definition Display
The LED bus display uses small-pitch LEDs for higher resolution and improved advertising effect. Outdoor high-brightness LEDs make the display brighter than 4500 cd/m², ensuring crystal clear content that is highly visible even in daylight, providing excellent advertising display.
Wireless Controlin Cluster by 4G
The LED bus display with integrated 4G module allows multiple control and synchronous updates through the publishing platform, supporting simple and easy wireless operation.
Displavs in Large-Scale and Individualized
The LED bus display with 4G integration enables multiple control and synchronized updates through the publishing platform. Easy wireless operation ensures real-time adjustment and release of advertising information with timeliness and accuracy. These displays provide both uniform appearance and personalized displays, allowing buses to reflect unique personalities in large-scale publicity for flexible, efficient advertising solutions.
Easy Publication,User-Friendly Management
Online and direct publication with flexible customization makes management timely and convenient, elevating efficiency. Big data analysis allows for monitoring and evaluation anytime.
Bus led display installation steps
Tips: Each car model has different mounting brackets and different mounting bracket lengths. Corresponding installation methods can be designed.
Bus led display led display parameter introduction
| Item | VSB-A2.5 | VSB-A3.076 | VSB-A4 | VSB-A5 |
| Pixel | 2.5 | 3.076 | 4 | 5 |
| Led type | SMD1921 | SMD 1921 | SMD1921 | SMD2727 |
| Pixel Densitydots/m2 | 160000 | 71110 | 62500 | 40000 |
| Display SizeW*Hmm | 1600*320 | 1600*320 | 1600*320 | 1600*320 |
| Cabinet SizeW*H*D mm | 1630x325x65 | 1630x324x65 | 1630x325x65 | 1630x325x65 |
| Cabinet Resolutiondots | 648*128 | 320*160 |
400*80 | 320*64 |
| Cabinet WeightKg/unit | 18~20 | 18~20 | 18~20 | 18~20 |
| Cabinet Material | Iron | Iron | Iron | Iron |
| BrightnessCD/㎡ | ≥4500 | ≥4500 | ≥4500 | ≥4500 |
| Viewing Angle | V160°/H 140° | V160°/H 140° | V160°/H 140° | V160°/H 140° |
| Ave.Power ConsumptionW/set | 140 | 130 | 100 | 80 |
| Input VoltageV | 24 | 24 | 24 | 24 |
| Refresh RateHz | 1920 | 1920 | 1920 | 1920 |
| Operation Temperature°C | -30~80 | -30~80 | -30~80 | -30~80 |
| Working Humidity(RH) | 10%~80% | 10%~80% | 10%~80% | 10%~80% |
| Ingress Protection | IP30 | IP30 | IP30 | IP30 |
| Control Way | Android+4G+AP+WiFi+GPS+8GB Flash | |||
