Connector, RJ45 1*N and 2*N Series, with LED/Shiled 90 or 180 degree Featured Image
  • Connector, RJ45 1*N and 2*N Series, with LED/Shiled 90 or 180 degree

Connector, RJ45 1*N and 2*N Series, with LED/Shiled 90 or 180 degree

Short Description:

● Connector information: 2*N series, with and without shiled, and LED light● Contact: Phosphor Bronze, Gold plated● Housing: PBT, UL 94 V-0● Samples Policy: We offer samples charge samples cost、shipping and tax paid by buyer● Shipment: UPS/FEDEX/ SF● Normal samples time: 1 Weeks, Mass production time: 2~3Weeks


Download as PDF

Product Detail

Product Tags

1*N Series

● RJ45 1*N Series Connectors with or without transformer

● Main Application:
RJ45 Ethernet Jack sopport multiple ports 1*1，1*2, 1*3,1*4,1*5,1*6 ,1*7,1*8
Support 10/100 Gigabit/2.5G/10G ethernet Lan port
Support Hight-Speed Cat5,Cat5e, Cat6, Bandwidth 2.4~2.5GHz

● P/N: CN1D-XX-0002

2*N Series

● RJ45 2*N Series Connectors with or without transformer

● Main Application:
RJ45 Ethernet Jack sopport multiple ports 2*1，2*2, 2*3,2*4,2*5,2*6
Support 10/100 Gigabit/2.5G/10G ethernet Lan port
Support Hight-Speed Cat5,Cat5e, Cat6, Bandwidth 2.4~2.5GHz

● P/N: CN1D-XX-0001

Description

Housing Thermoplastic polyester UL 94 V-0
Terminal Round Pin and Flat PINs, gold plated over nickel in contact, tinned plating over nickel in solder area
Voltage rating 125V AC RMS
Current rating 1.5 A
Contact resistance 40 milliohms maximum
Insulation resistance 1000Megohms minimum at 500V DC
Dieletric strength 1000V AC RMS 50Hz 1 minute
Operating 750 Cycles/minute
Storage -40˚C to +85˚C
Operating Temperature 0˚C to +70˚C

Electrical

*100% open short testing
*Conductive resistance  2ohm Maximum
*Insulation Resistance  10M ohm Minimum@300V DC
1*N Series  P/N  CN1D-XX-0002
2*N Series P/N  CN1D-XX-0001
Brand Name   or Customized
Origin  Made in China
Work Standard  Per IPC-A-620

Specification

Weight per Unit  30 grams
Dimensions per Unit  21*15*2 Centimeters
1*N SeriesUnits per export carton  1000PCS
2*N Series Units per export carton  500PCS
Export Carton weight  15Kilograms
All raw materials must be meet Rosh

Packaging Style

Cable tie with PE BAG per Pcs
Cable length  1Meter other Customized
Carton Box Size  Normal use Box

1*N Series Product Display

2*N Series Product Display
