CR314 Low Power Cost ISO15693 Reader module

Short Description:

Product number: CR314Product feature: Low power consumption, wide voltage; ARM M0 32K Flash with ST25R3911/ST25R668; Work mode can be customized; ISO14443 TYPE A/B, T=CL ISO15693; Industrial design, wide temperature working environment adaptation; Customizable parting.




Product Detail

Product Tags

13.56Mhz card reader module CR314

CR314A
MIFARE® 1k/4K, UltraLight, Ntag, NTAG203, NTAG213, NTAG215, NTAG216

CR314D
25TV512 ,25TV02K,25TV04K

Application scopes

  • e-Government
  • Banking & Payment
  • Access Control Time Attendance
  • Network Security
  • e-Purse & Loyalty
  • Transportation
  • Kiosk
  • Intelligent Meters

Technical parameter

  • Power supply: 2.5V–3.6V, 40-105mA
  • After dormancy current:12UA
  • Interface: RS232 or TTL232
  • Transmission speed: Default 19200 bps
  • R/W distance of up to 60mm (up to 100mm with bigger antenna size), depending on TAG
  • Storage temperature: -40 ºC ~ +85 ºC
  • Operating temperature: -40ºC ~ +70 ºC
  • ISO14443A ISO14443B  ISO15693

feature

CR314 reader card module uses RFID IC ST25R3911 Or ST25R668 and ARM0 32K Flash MCU

  • ISO 18092 (IP-1) Active P2P
  • ISO14443A, ISO14443B, ISO15693 and FeliCa™
  • Automatic antenna tuning system providing tuning of antenna LC tank
  • Automatic modulation index adjustment
  • AM and PM demodulator channels with automatic selection
  • User selectable and automatic gain control
  • Transparent and stream modes to implement MIFARE™ classic compliant or other custom protocols
  • Possibility of driving two antennas in single ended mode
  • Oscillator input capable of operating with 13.56 MHz or 27.12 MHz crystal with fast start-up
  • 6 Mbit/s SPI with 96 bytes FIFO
  • Wide supply voltage range from 2.4 V to 5.5 V
  • Wide temperature range: -40 °C to 125 °C
  • QFN32, 5 mm x 5 mm package

ISO 18092 (IP-1) initiator, ISO 18092 (IP-1) active target, ISO 14443A and B reader (including high bit rates), ISO 15693 reader and FeliCa™ reader.

Default communication Settings

The communication protocol is byte oriented.
Both sending and receiving bytes are in hexadecimal format.
The communication parameters are as follows,
Baud rate: 19200 bps
Data: 8 bits
Stop: 1 bit
Parity: None
Flow control: None

Dimensions and related parameters

name CR314 series Proximity Reader Module
Net weight 12g
dimension 40*60(mm)
Operating temperature -40 ~ +85℃
Interface COMS UART or IC, Default UART
Card reading distance up to 8cm, ISO15693 15Cm
frequency 13. 56MHz
Applicable card type Depends on the program version
MIFARE® 1K, MIFARE®4K, MIFARE Utralight®,Ntag, MIFARE Utralight®C, SLE66R35, Fm1108, TYPE A CPU card25TB512, 25TB04K, 25TB176ISO15693 I.code SLIx, I.code SLIs, TI2k, TI256, ST25TV512/2k/04K, ST25DV512/2k/04K
Operating voltage, current DC2.5- 3.6V, 40ma – 100ma , Sleep Mode 5uA
MCU Core: ARM® 32- bit CortexTM -M0 CPU
CR314A CR314B CR314D CR9505F
ISO14443A
ISO14443B
ISO15693

CR314 Similar product description

Model

Description

Interface &  Others

CR0385A/B

MIFARE® S50/S70, Ultralight®, FM1108, TYP

25TB512, 25TB04K, 25TB176

UART DC

2.6~5.5V

CR9505

MIFARE® 1K/4K, Ultralight®, Ultralight®C, Mifare®Plus FM1108, TYPE

A.Ntag, SLE66R01P, typeA tags

l.code sliTi 2k, SRF55V01, SRF55V02, SRF55V10, LRI

2k, ISO15693 STD

25TB512, 25TB04K, 25TB176

2.6~5.5V

CR0381D

l.code sliTi 2k, SRF55V01, SRF55V02, SRF55V10, LRI

2k, ISO15693 STD

UART DC

2.6~3.6V

Other similar products

Model Description InterFace
CR0301A MIFARE® TypeA reader modulMIFARE® 1K/4K, Ultralight®, Ntag. Sle66R01Pe UART & IIC2.6~3.6V
CR0285A MIFARE® TypeA reader moduleMIFARE® 1k/4k, Utralight®, Ntag. Sle66R01P UART OR SPI2.6~3.6V
CR0381A MIFARED TypeA reader moduleMIFARE® S50/S70, Ultralight®.Ntag. Sle66R01P UART
CR0381D I.code sli, Ti 2k, SRF55V01, SRF55V02, SRF55V10, LRI2K, ISO15693 STD UART DC 5V OR|DC 2.6~3.6V
CR8021A MIFARE®TypeA reader moduleMIFARE® S 50/S70, Ultralight®, Ntag. Sle66R01P RS232 or UART
CR8021D .code sli.Ti 2k, SRF55V01, SRF55V02, SRF55V10, LRI2K, ISO15693 STD RS232 OR UARTDC3VOR5V
CR508DU-K 15693 UID Hex output USB EmulationKeyboar
CR508AU-K TYPE A, MIFARE® UID or Block Data output USB EmulationKeyboard
CR508BU-K TYPE B UID Hex output USB EmulationKeyboard
CR6403 TYPEA(MIFARE Plus®, Ultralight® C) + TYPEB+ISO15693 + Smart Card UART RS232 USB|IC
CR6403 TYPEA(MIFARE Plus®, Ultralight® C)+ TYPEBISO15693 + Smart Card+ USB RS232
CR9505 TYPEA(MIFARE Plus®, Ultralight® C)+ TYPEBISO15693 UART

COMMENT:  MIFARE® and MIFARE Classic® are trademarks of NXP B.V. Function and model please check with our technical service department.
