D Pale Palisade Fence
Description
Palisade fencing offers the best there is in a security fence, a durable versatile fence at a cost effective price.Simple to install, the individual components are hot dip galvanized prior to leaving our factory and no further welding,
cutting or drilling is necessary, ensuring total corrosion protection and minimizing installation time and costs.
Palisade is more secure than other fencing systems, so wherever security is a priority, Palisade is used.Steel palisade fencing is especially popular for schools,park and industrial sites because of its high damage resistance and the fact that it is so difficult to climb.
As palisade fencing manufacturer, supply both the “D” section style of palisade fencing 65 width and 62 width style, with the integrity of the palisade fence being maintained by the two horizontal rails that are used as standard in palisade fences up to three meters high. However, we can supply other heights of palisade fencing as your required.
Pale head:Can be do single pointed, triple pointed, rounded or round and notched tops only.
Palisade fence features
1. Bolt-on Palisade fencing can be installed by semi-skilled staff as there is no welding on site.
2. Bolt-on Palisade fencing is easily transported. The components are packed in bundles.
3. Bolt-on Palisade fencing which has been hot-dip galvanized is not compromised by welding on site.
4. Bolt-on Palisade fencing can be easily moved to another fence line.
5. Palisade fencing is modular.Sections can be replaced easily if damaged by vehicles,falling trees,etc.
6. Palisade fencing is modular.Sections can be replaced easily if damaged by vehicles,falling trees,etc.
7. Design is nice looking
8. Cost is less than other high security fence
9. Long time to anti rust , Enough corrosion ability over 10 years.
10. Enhance high security ,add concertina wire is available.
Palisade fence application
It is often used in ELECTRICITY ,NET WORKS,WATER,TELECOM industry. PLANTS, GARDEN,ISOLATED OF ROAD,SCHOOL,RESIDENCE COMMUNITY ,ETC.
Specifications
|
Panel size |
D Pale section: 65mm |
Rails |
Post |
||
|
Fence heights |
Post Distance |
Pale Thickness |
Qty of Pale |
Cross Rails |
Height |
|
1.8m |
2.75m |
2/2.5/3mm |
17pcs |
50×50×6mm |
2400 |
|
2.1m |
2.75m |
2/2.5/3mm |
17pcs |
50×50×6mm |
2900 |
|
2.4m |
2.75m |
2/2.5/3mm |
17pcs |
50×50×6mm |
3200 |
|
3.0m |
2.75m |
2/2.5/3/3.5mm |
17pcs |
50×50×6mm |
3900 |
|
D Pale section:62mm |
|||||
|
1.8m |
2.75m |
1.5/2/2.5mm |
17pcs |
40×40×4mm or |
2400 |
|
2.1m |
2.75m |
1.5/2/2.5mm |
17pcs |
40×40×4mm or |
2900 |
|
2.4m |
2.75m |
1.5/2/2.5mm |
17pcs |
40×40×4mm or |
3200 |
|
3.0m |
2.75m |
1.5/2/2.5mm |
17pcs |
40×40×4mm or |
3900 |
Material
Pale use mild steel plate(black or galvanized)
Horizontal rails:Standard 50×50×6mm angle rail
Post use I beam( IPE 100×55mm, IPE 100×68mm,120×74mm)or square post （80×80,100×100mm)
Fixings:Steel plate:40×8×150mm
Bolts:M8×30,M12×30 anti-vandal steel or stainless steel
Surface:Galvanized or galvanized then powder coating finished
Steel grade can be chose.
Trade item
Delivery Terms :FOB, CIF
Payment Currency:USD, EUR, AUD,JPY, CAD, GBP, CNY
Payment Item:T/T, L/C, PayPal, Escrow
Nearest Port:Xingang port,Qingdao port
Delivery Time:General after 25days upon received T/T30% advance payment
Payment detail: T/T 30% in advance as deposit, the balance against received the copy of B/L.
