DC-40GHz Power Divider Series
Description
DC-40GHz Power Divider Series for Wide applications
As the manufacturer of power divider, Jingxin can design and produce it from DC-40GHz, there are some standard power dividers for reference, including 2 way, 3 way, 4 way, 5 way, 6 way, 8 way, 12 way, 16 way in different frequency. It can be cavity or microstrip structure. These power dividers are widely used for commercial and military applications. Jingxin also offer ODM & OEM service according to the client’s demand.
As promised, all the RF passive components from Jingxin have 3 years warranty.
Parameter
| Item No. | Frequency Range | Way | Insertion Loss Max | Power | VSWR | Isolation Min | PIM3 | Connector | Dimension(L*W*H） |
| JX-PD-66-1000-02QNF | 66-1000MHz | 2-way | 3.8dB(66-900MHz) 4.0dB(900-1000MHz) | 100W | 1.4: 1 | 16dB@66-80MHz 18dB@80-1000M | ≤-140dBc @2*43dBm | QN-Female | 281 x 144.4 x 30mm |
| JX-PD2-134M3700M-18N | 134-3700MHz | 2-way | 2.2dB | 30W | 1.3: 1 | 18dB | - | N-Female | 111 x 50 x 20mm |
| JX-PD3-134M3700M-18N | 134-3700MHz | 3-way | 3.8dB | 30W | 1.5: 1 | 18dB | - | N-Female | 280 x 68 x 20mm |
| JX-PD4-134M3700M-18N | 134-3700MHz | 4-way | 4.2dB | 30W | 1.4: 1 | 18dB | - | N-Female | 215 x 96 x 20mm |
| JX-PD6-200M800M-18SH | 200-800MHz | 6-way | 1.2dB | 50W | 1.4: 1 | 18dB | - | SMA-Female | 200 x190 x 14mm |
| JX-PD6-200M800M-18SL | 200-800MHz | 6-way | 2.0dB | 50W | 1.3:1 | 18dB | - | SMA-Female | 198 x 138 x 13mm |
| JX-PD-300-960-02N | 300-960MHz | 2-way | 0.3dB | 100W | 1.25:1 | 20dB | ≤-130dBc@2*43dBm | N-Female | 88 x 88 x 22mm |
| JX-PD-300-960-03N | 300-960MHz | 3-way | 0.5dB | 100W | 1.25:1 | 20dB | ≤-130dBc@2*43dBm | N-Female | 139 x 117 x 22 |
| JX-PD-300-960-04N | 300-960MHz | 4-way | 0.4dB | 100W | 1.25:1 | 20dB | ≤-130dBc@2*43dBm | N-Female | 147 x 137 x 22mm |
| JX-PD-340M2000M-20N | 340-2000MHz | 2-way | 0.8dB | 50W | 1.5: 1 | 20dB | ≤-150dBc@2*43dBm | N-Female | 133 x 88 x 20mm |
| JX-PS-380M2700M-2N | 380-2700MHz | 2-way | 0.25dB | 300W | 1.5: 1 | - | ≤-150dBc@2*43dBm | N-Female | 283.2 x 61 x 20mm |
| JX-PS-380M2700M-3N | 380-2700MHz | 3-way | 0.35dB | 300W | 1.3:1 | - | ≤-150dBc@2*43dBm | N-Female | 293.9 x 61 x 20mm |
| JX-PS-380M2700M-3N | 380-2700MHz | 4-way | 0.45dB | 300W | 1.35:1 | - | ≤-150dBc@2*43dBm | N-Female | 293.9 x 61 x 20mm |
| JX-PD4-500M8000M-20S | 500-8000MHz | 4-way | 3.0dB | 30W | 1.18:1 | 25dB | - | SMA- Female | 132 x 64 x 12mm |
| JX-PD2-575M3800M-N300 | 575-3800MHz | 2-way | 0.3dB | 30W | 1.2:1 | - | ≤-155dBc@2*43dBm | N-Female | 224.3 x 60.8 x 25mm |
| JX-PD2-575M3800M-DINF300 | 575-3800MHz | 2-way | 0.3dB | 300W | 1.2:1 | - | ≤-155dBc@2*43dBm | 7/16(DIN)-Female | 226 x 64.2 x 25mm |
| JX-PD2-575M3800M-4310F300 | 575-3800MHz | 2-way | 0.3dB | 300W | 1.2:1 | - | ≤-155dBc@2*43dBm | 4.3-10/Female | 227.3 x 66.8 x 25mm |
| JX-PD3-575M3800M-N300 | 575-3800MHz | 3-way | 0.4dB | 300W | 1.25:1 | - | ≤-155dBc@2*43dBm | N-Female | 277 x 60.8 x 25mm |
| JX-PD3-575M3800M-DINF300 | 575-3800MHz | 3-way | 0.4dB | 300W | 1.25:1 | - | ≤-155dBc@2*43dBm | 7/16(DIN)-Female | 280.4 x 64.2 x 25mm |
| JX-PD3-575M3800M-4310F300 | 575-3800MHz | 3-way | 0.4dB | 300W | 1.2:1 | - | ≤-155dBc@2*43dBm | 4.3-10/Female | 283 x 66.8 x 25mm |
| JX-PD4-575M3800M-N300 | 575-3800MHz | 4-way | 0.5dB | 300W | 1.3:1 | - | ≤-155dBc@2*43dBm | N-Female | 277 x 60.8 x 25mm |
| JX-PD4-575M3800M-DINF300 | 575-3800MHz | 4-way | 0.5dB | 300W | 1.3:1 | - | ≤-155dBc@2*43dBm | 7/16(DIN)-Female | 280.4 x 64.2 x 25mm |
| JX-PD4-575M3800M-4310F300 | 575-3800MHz | 4-way | 0.5dB | 300W | 1.3:1 | - | ≤-155dBc@2*43dBm | 4.3-10/Female | 283 x 66.8 x 25mm |
| JX-PS-575-6000-2C43DI | 575-6000MHz | 2-way | 0.2dB(575-2700MHz) | 300W | 1.25:1 | - | ≤-160 dBc@2x43dBm | 4.3/10-Female | 270 x 25 x 25mm |
| 0.4dB(2700-6000MHz) | |||||||||
| JX-PS-575-6000-3C43DI | 575-6000MHz | 3-way | 0.2dB(575-2700MHz) | 300W | 1.25:1 | - | ≤-160 dBc@2x43dBm | 4.3/10-Female | 205.4 x 25 x 25mm |
| 0.4dB(2700-4900MHz) | |||||||||
| 0.9dB(4900-6000MHz) | |||||||||
| JX-PS-575-6000-4C43DI | 575-6000MHz | 4-way | 0.3dB(575-2700MHz) | 300W | 1.25:1 | - | ≤-160 dBc@2x43dBm | 4.3/10-Female | 255 x 25 x 25mm |
| 0.4dB(2700-3800MHz) | |||||||||
| 0.6dB(3800-4900MHz) | |||||||||
| 1.3dB(4900-6000MHz) | |||||||||
| JX-PD-698-2700-2N | 698-2700MHz | 2-way | 0.4dB | 100W | - | - | ≤-130dBc@2*43dBm | N-Female | 107×79 x 22mm |
| JX-PD-698-2700-3N | 698-2700MHz | 3-way | 0.6 dB | 50W | - | - | ≤-130dBc@2*43dBm | N-Female | 135 x111 x 22mm |
| JX-PD-698-2700-4N | 698-2700MHz | 4-way | 0.6 dB | 100W | - | - | ≤-130dBc@2*43dBm | N-Female | 141×129 x 22mm |
| JX-PD1-700M2700M-20S-1 | 700-2700MHz | 2-way | 0.4dB | 30W | 1.2: 1 | 20dB | - | SMA-Female | 40 x 36 x 12mm |
| JX-PD-800M3800M-2N | 800-3800 MHz | 2-way | 3.5dB | 50W | 1.25: 1 | 20dB | ≤-150dBc@2*33dBm | N-Female | 100 x 45 x 20mm |
| JX-PD1-700M2700M-20S-1 | 700-2700MHz | 2-way | 0.4dB | 30W | 1.2: 1 | 20dB | - | SMA-Female | 40 x 36 x 12mm |
| JX-PD-800M3800M-2N | 800-3800 MHz | 2-way | 3.5dB | 50W | 1.25: 1 | 20dB | ≤-150dBc@2*33dBm | N-Female | 100 x 45 x 20mm |
| JX-PD2-1G18G-18S | 1000-18000MHz | 2-way | 1.2dB | 20W | 1.4: 1 | 20dB | - | SMA- Female | 99 x 24 x 10mm |
| JX-PD4-1G18G-16S | 1000-18000MHz | 4-way | 3.0dB | 20W | 1.4: 1 | 18dB | - | SMA- Female | 99 x 71 x 10mm |
| JX-PD2-2G8G-20N | 2000-8000MHz | 2-way | 0.8dB | 30W | 1.25: 1 | 20dB | - | N- Female | 38 x 29 x 20mm |
| JX-PD8-2G18G-16S | 2000-18000MHz | 8-way | 3.2dB | 20W | 1.5: 1 | 18dB | - | SMA- Female | 148.5 x 95 x 10mm |
| JX-PD2-4G8G-20S | 4000-8000MHz | 2-way | 0.3dB | 30W | 1.25: 1 | 20dB | - | SMA- Female | 28 x 28 x 10mm |
| JX-PD4-7G8.5G-18N | 7000-8500MHz | 4-way | 1.0dB | 30W | 1.4: 1 | 18dB | - | N- Female | 97 x 49 x 20mm |
| JX Model # | Ways | Frequency | Insertion | VSWR | Isolation | Amplitude | Phase | Input |
| Range | Loss | Balance | Balance | Power | ||||
| JX-PD2-DC40G-1W | 2-way | DC-40GHz | 7.50dB | 1.5/2.5 | 12dB | ±0.40dB | ±5° | 1W |
| JX-PD4-DC40G-1W | 4-way | DC-40GHz | 15.0dB | 1.9/2.5 | 10dB | ±0.60dB | ±7° | 1W |
| JX-PD8-DC40G-1W | 8-way | DC-40GHz | 23.0dB | 1.6/2.5 | 10dB | ±0.10dB | ±10° | 1W |
| JX-PD2-10M1800M-2W | 2-way | 0.01-1.8GHz | 1.60dB | 2.10:1 | 18dB | ±0.30dB | N/A | 2W |
| JX-PD4-10M1800M-2W | 4-way | 0.01-1.8GHz | 4.00dB | 2.80:1 | 18dB | ±0.40dB | N/A | 2W |
| JX-PD8-10M1800M-2W | 8-way | 0.01-1.8GHz | 6.00Db | 2.80:1 | 18dB | ±0.70dB | N/A | 2W |
| JX-PD2-698M2700M-50W | 2-way | 0.698-2.7GHz | 0.35dB | 1.30 : 1 | 18dB | ±0.20dB | ±3° | 50W |
| JX-PD3-698M2700M-30W | 3-way | 0.698-2.7GHz | 1.00dB | 1.35:1 | 18dB | ±0.30dB | N/A | 30W |
| JX-PD4-698M2700M-30W | 4-way | 0.698-2.7GHz | 0.70dB | 1.30 : 1 | 18dB | ±0.34dB | ±4° | 30W |
| JX-PD2-0.7G3G-30W | 2-way | 0.7-3GHz | 0.60dB | 1.20 : 1 | 24dB | ±0.20dB | ±2° | 30W |
| JX-PD3-0.7G3G-30W | 3-way | 0.7-3GHz | 0.90dB | 1.40 : 1 | 22dB | ±0.60dB | ±4° | 30W |
| JX-PD4-0.7G3G-30W | 4-way | 0.7-3GHz | 0.80dB | 1.30 : 1 | 20dB | ±0.40dB | ±4° | 30W |
| JX-PD6-0.7G3G-30W | 6-way | 0.7-3GHz | 1.20dB | 1.40 : 1 | 18dB | ±0.60dB | ±5° | 30W |
| JX-PD8-0.7G3G-30W | 8-way | 0.7-3GHz | 1.50dB | 1.40 : 1 | 18dB | ±0.50dB | ±4° | 30W |
| JX-PD12-0.7G3G-30W | 12-way | 0.7-3GHz | 2.00dB | 1.40 : 1 | 18dB | ±0.80dB | ±5° | 30W |
| JX-PD16-0.7G3G-30W | 16-way | 0.7-3GHz | 2.00dB | 1.50 : 1 | 18dB | ±0.80dB | ±5° | 30W |
| JX-PD2-0.5G4G-30W | 2-way | 0.5-4GHz | 0.50dB | 1.30 : 1 | 20dB | ±0.20dB | ±2° | 30W |
| JX-PD4-0.5G4G-30W | 4-way | 0.5-4GHz | 1.00dB | 1.40 : 1 | 18dB | ±0.40dB | ±4° | 30W |
| JX-PD8-0.5G4G-30W | 8-way | 0.5-4GHz | 1.80dB | 1.50 : 1 | 18dB | ±0.50dB | ±5° | 30W |
| JX-PD2-1G4G-30W | 2-way | 1-4GHz | 0.40dB | 1.25 : 1 | 20dB | ±0.30dB | ±4° | 30W |
| JX-PD4-1G4G-30W | 4-way | 1-4GHz | 0.70dB | 1.25 : 1 | 20dB | ±0.30dB | ±4° | 30W |
| JX-PD8-1G4G-30W | 8-way | 1-4GHz | 1.20dB | 1.25 : 1 | 20dB | ±0.50dB | ±5° | 30W |
| JX-PD2-2G4G-30W | 2-way | 2-4GHz | 0.40dB | 1.20 : 1 | 20dB | ±0.20dB | ±2° | 30W |
| JX-PD4-2G4G-30W | 4-way | 2-4GHz | 0.60dB | 1.20 : 1 | 20dB | ±0.20dB | ±2° | 30W |
| JX-PD8-2G4G-30W | 8-way | 2-4GHz | 1.00dB | 1.25 : 1 | 20dB | ±0.30dB | ±4° | 30W |
| JX-PD16-2G4G-30W | 16-way | 2-4GHz | 1.00dB | 1.25 : 1 | 18dB | ±0.30dB | ±7° | 30W |
| JX-PD2-2G8G-30W | 2-way | 2-8GHz | 0.60dB | 1.30 : 1 | 20dB | ±0.20dB | ±2° | 30W |
| JX-PD3-2G8G-30W | 3-way | 2-8GHz | 1.10dB | 1.45：1 | 18dB | ±0.60dB | ±6° | 30W |
| JX-PD4-2G8G-30W | 4-way | 2-8GHz | 0.80dB | 1.40 : 1 | 20dB | ±0.50dB | ±3° | 30W |
| JX-PD6-2G8G-30W | 6-way | 2-8GHz | 1.50dB | 1.45：1 | 18dB | ±0.70dB | ±7° | 30W |
| JX-PD8-2G8G-30W | 8-way | 2-8GHz | 1.40dB | 1.50 : 1 | 18dB | ±0.50dB | ±5° | 30W |
| JX-PD12-2G8G-30W | 12-way | 2-8GHz | 1.80dB | 1.60 : 1 | 16dB | ±0.80dB | ±8° | 30W |
| JX-PD2-1G12.4G-30W | 2-way | 1-12.4GHz | 1.20dB | 1.40 : 1 | 18dB | ±0.30dB | ±4° | 30W |
| JX-PD4-1G12.4G-30W | 4-way | 1-12.4GHz | 2.20dB | 1.70 : 1 | 16dB | ±0.50dB | ±7° | 30W |
| JX-PD8-1G12.4G-30W | 8-way | 1-12.4GHz | 3.50dB | 1.80 : 1 | 16dB | ±0.70dB | ±8° | 30W |
| JX-PD2-6G18G-30W | 2-way | 6-18GHz | 0.80dB | 1.40 : 1 | 18dB | ±0.30dB | ±6° | 30W |
| JX-PD3-6G18G-30W | 3-way | 6-18GHz | 1.00dB | 1.50 : 1 | 18dB | ±0.60dB | ±6° | 30W |
| JX-PD4-6G18G-30W | 4-way | 6-18GHz | 1.20dB | 1.60 : 1 | 18dB | ±0.50dB | ±6° | 30W |
| JX-PD6-6G18G-30W | 6-way | 6-18GHz | 1.50dB | 1.70 : 1 | 18dB | ±0.50dB | ±6° | 30W |
| JX-PD8-6G18G-30W | 8-way | 6-18GHz | 2.10dB | 1.80 : 1 | 18dB | ±0.60dB | ±8° | 30W |
| JX-PD2-2G18G-30W | 2-way | 2-18GHz | 1.20dB | 1.50 : 1 | 18dB | ±0.50dB | ±5° | 30W |
| JX-PD4-2G18G-30W | 4-way | 2-18GHz | 2.00dB | 1.70 : 1 | 18dB | ±0.80dB | ±8° | 30W |
| JX-PD8-2G18G-30W | 8-way | 2-18GHz | 3.50dB | 1.80 : 1 | 15dB | ±1.00dB | ±10° | 30W |
| JX-PD2-1G18G-30W | 2-way | 1-18GHz | 1.50dB | 1.50 : 1 | 16dB | ±0.40dB | ±5° | 30W |
| JX-PD4-1G18G-30W | 4-way | 1-18GHz | 2.20dB | 1.70 : 1 | 16dB | ±0.60dB | ±6° | 30W |
| JX-PD8-1G18G-30W | 8-way | 1-18GHz | 4.00dB | 2.00 : 1 | 15dB | ±0.90dB | ±12° | 30W |
| JX-PD2-0.5G18G-30W | 2-way | 0.5-18GHz | 1.70dB | 1.60 : 1 | 16dB | ±0.50dB | ±5° | 30W |
| JX-PD4-0.5G18G-30W | 4-way | 0.5-18GHz | 4.00dB | 1.70 : 1 | 16dB | ±0.50dB | ±8° | 30W |
| JX-PD8-0.5G18G-30W | 8-way | 0.5-18GHz | 6.00dB | 1.70 : 1 | 13dB | ±0.90dB | ±12° | 30W |
| JX-PD2-6G40G-10W | 2-way | 6-40GHz | 1.50dB | 1.60 : 1 | 16dB | ±0.40dB | ±5° | 10W |
| JX-PD4-6G40G-10W | 4-way | 6-40GHz | 1.80dB | 1.60 : 1 | 16dB | ±0.40dB | ±8° | 10W |
| JX-PD8-6G40G-10W | 8-way | 6-40GHz | 3.50dB | 2.00 : 1 | 15dB | ±0.80dB | ±9° | 10W |
| JX-PD2-18G40G-20W | 2-way | 18-40GHz | 1.20dB | 1.50:1 | 16dB | ±0.40dB | ±4° | 20W |
| JX-PD4-18G40G-20W | 4-way | 18-40GHz | 1.60dB | 1.70/1.50 | 16dB | ±0.40dB | ±6° | 20W |
| JX-PD8-18G40G-20W | 8-way | 18-40GHz | 2.00dB | 1.80/1.50 | 16dB | ±0.50dB | ±8° | 20W |
Custom RF Passive Components
As a manufacturer of RF passive components, Jingxin can design various ones according to the clients’ applications.
Only 3 Steps to Solve Your Problem of RF Passive Component
1.Defining the parameter by you.
2.Offering the proposal for confirmation by Jingxin.
3.Producing the prototype for trial by Jingxin.
Only 3 Steps to Solve Your Problem of RF Passive Component
1.Defining the parameter by you.
2.Offering the proposal for confirmation by Jingxin.
3.Producing the prototype for trial by Jingxin.
