1.Ultra-thin edge design: Rapidly integrates with the surrounding environment, making it difficult to find the connection between the lamp and the ceiling.
2.Modular design,a variety of face rings and reflectors to choose,reduce sales inventory
3.Die-cast aluminum material guarantees corrosion protection,rust prevention and better heat dissipation
4.Deep anti-glare design provide sufficient light for general lighting without glare,bring a cozy and warm ambiance for your sight.
5.CRI>80:The color index is up to 80Ra,which is the natural color closer to the object being illuminated,built in COB chips,good color and high brightness.
6.Three colors are optional, you can choose according to your needs. Different color temperatures bring people different feelings, which can meet the needs of various places
7.different colors reflector for your option:DIY the appearance of your lamp whenever you like,modular design,reduce the inventory
8.Surface ring color and photoelectric equipment change various option freely to satisfy different request,meanwhile it can reduce pressure of customer stock
9.Ultra low glare for max comfort,UGR<19,Slim and narrow trim design, nice ceiling apperance after installtion,Outter ring can be sold independantly
10.High quality driver:IC solution with stable performance ,high quality,and long life
11.Modular LED engine,excellent optical design with high efficiency heat sink.
12.Deep regress aperture,brand name lens+reflector,this ensure UGR<19,for max visual comfort in office or leisure space
13.Compact heat sink with deep fins,it ensure good thermal management and long led lifetime
14.Thin and narrow trim design,nice appearance on ceiling after installation
15.Different brand driver can be supplied,meeting your requirement on EMC/PF and budget
16.It is specailly developed for high-end and advanced places,such as 5-start hotel,private villa,shopping mall,luxury store and so on
CCT | 3000K/4000K/6000K |
Lamp Luminous Efficiency(lm/w) | 80-100 |
IP Rating | IP20 |
Install style | Recessed |
Optional Control | Triac/0-10V/DALI |
Operating temperature | -20℃-+40℃ |
Working Life | 30000H |
Ouput voltage | 220-240V 50/60Hz |
Transformer mounting | built-out |
Control | standard on/off |
Housing Color | White |
Certificate | CE/RoHS |
Warrenty | 3 years |
Applications | livingroom,home,hotel,offices,conference room,Lobby,Hallway |
Code | Watt | Lumen(lm) | Optic | Cut-out(mm) | Size(mm) | Installation |
8851361 | 7W | 580lm | 15/24/40° | 75 | φ82*86 | recessed |
8851362 | 18W | 1370lm | 15/24/40° | 125 | φ132*135 | recessed |
8851363 | 30W | 2260lm | 15/24/40° | 150 | φ157*140 | recessed |
