☆ Feature
1. 600 ° C high temperature tempering treatment of the rack and the whole processing is not deformed.
2. Bilateral drive, stable operation, high cutting precision and fast speed.
3. Original imported motor, reducer, high precision gears, racks, guides.
4. Built-in cooling and exhausting environmental protection system.
5. Fully automatic oil lubrication, low noise and maintenance free.
☆ Machine photos :
☆ Machine parameters:
Model | BTD-1530 |
Input power | AC380V/50HZ,AC 220V/50Hz |
Track gauge(mm) | 1865 |
Track length(mm) | 3500 |
Effective cutting width(mm) | 1500 |
Machine width(mm) | 1840 |
Lift(mm) | 100 |
Cutting thickness(mm) | Plasma: 1~20 (According to the power supply size) |
Cutting speed (mm/min) | 0~8000 |
Idle speed | 0~12000 |
Drive mode | Precision rack bilateral drive |
System | Shanghai Jiaoda or Beijing Starfire |
Operating accurancy | ±0.5mm |
☆ Samples:
