Diesel Hydraulic Material Handler WZY32-8C
6. WZY32-8C is suitable for loading and unloading, stacking, transshipment and packaging of scrap steel yard, wharf yard, railway yard, garbage treatment and light material industry.
7. The diesel engine emissions of WZY32-8C comply with the latest environmental regulations, the engine also can be selected according to customer requirements and local fuel specifications. WZY32-8C is equipped with world-renowned brand draulic components and parts.
8. WZY32-8C has a variety of optional functions, which can fully meet the individual needs of customers. Including: elevating cab, fixed heightened cab, video surveillance/display system, electronic weighing system, radiation detection system, automatic centralized lubrication system, rubber track, etc.
9. A variety of tool options, including: multi-tooth grab, shell grab, wood grab, electromagnetic chuck, draulic shears, draulic clamp, etc.
WZY32-8C is a 31-ton diesel-powered material handler of . material handler is a high-efficiency special equipment for loading and unloading. It is specially designed for loading and unloading conditions. Mainly includes: structural optimization of operating devices and the whole machine, the optimization of the draulic system, the optimization of the undercarriage and balance, etc., it is not simple modifications of excavators.
| Item | Unit | Data |
| Machine weight | t | 31 |
| Diesel engine power | kW | 169 |
| Rated speed | rpm | 2000 |
| Max. flow | L/min | 2×224 |
| Max. operation pressure | MPa | 30 |
| Swing speed | rpm | 12.3 |
| Travel speed | km/h | 3.4/5.2 |
| Cycling time of operation | s | 16-22 |
| Working attachment | Data | |
| Boom length | mm | 6800 |
| Stick length | mm | 5800 |
| Capacity with multi-tine grab | m3 | 0.8 (semi-closure)/1.0 (open type) |
| Max. grabbing reach | mm | 13407 |
| Max. grabbing height | mm | 10874 |
| Max. grabbing depth | mm | 7415 |
1.Can it be supplied according to our local diesel engine specifications?
In general, we will supply Chinese standard diesel engines that are installed on our material handlers. If the corresponding diesel engines can be purchased, we can supply them according to the local diesel engines, but you need to contact us in advance to confirm and pay the additional cost, of course, it will be included in the final quotation.
2.Can I buy a material handler without a diesel engine, and then buy a local diesel engine to install on this material handler?
If it is material handler, unfortunately this is not available. We must be responsible for the quality, performance and even safety of the product.
3.How should I choose the model of material handler?
There are 4 very important questions that you need to consider first: What materials will be grabbed? What is the required operating efficiency? What is the required operating range/distance? What is the size limit of the site for the grabber? After you understand the information, please contact us and we will recommend the appropriate model to you.
Of course, you can also choose by knowing the models that are already used in similar sites. That is a relatively simple method.
4.For now, WZY32-8C more is being used in what kind of place?
Similar to WZY28-8C, except that WZY32-8C has a wider operating range and higher work efficiency.
5.Is there a wheel model to choose? Compared with the crawler type, will it be more expensive or cheaper?
Yes, you can choose wheel material handler BHW35-8. It will be more expensive.
