Specification

1. Elevation: ≤ 2500m
2. Ambient temperature: -25 ~ 55℃
3. Air relative humidity: 9 ~ 95%
4. Earthquake intensity: 7 degrees
5. Flow range: 50-700(L/S)
6. Lift range: 32-600m
7. Diesel engine power: 18-1100KW
8. Material of flow parts: cast iron, ductile iron, stainless steel, cast copper.
9. Diesel engine brands: Shangchai, Dongfeng, Cummins, Deutz, Fiat Iveco, Wuxi Power, Weichai, etc.

Diesel engine pump set main features

1. Automatic start: After receiving the fire alarm/pipe network pressure/power failure/or other starting signals, the diesel pump unit can automatically start and put into full load operation within 5 seconds;
2. Automatic charging: The battery can be automatically charged by the mains or diesel charging motor to ensure the smooth start of the unit;
3. Automatic alarm: automatic alarm protection for diesel engine faults such as low oil pressure and high water temperature, alarm and shutdown when speeding;
4. Automatic preheating: make the diesel engine in the heat engine standby state to ensure emergency work;
5. Direct connection: The diesel pump unit below 360kw adopts the domestic first diesel engine and the pump through the elastic coupling direct connection technology, which reduces the fault point, and greatly reduces the starting time of the unit, and increases the reliability and emergency performance of the unit;
6. Users can also request to set other alarm output (non-standard supply);
7. With telemetry, remote communication, remote control function (non-standard supply).
