Duplex Head Auger Filler (2 fillers)

Short Description:

This type of auger filler can do dosing and filling work. Due to the special professional design, it is suitable for the fluidic or low-fluidity materials, like milk powder, Albumen powder, rice powder, coffee powder, solid drink, condiment, white sugar, dextrose, food additive, fodder, pharmaceuticals, agriculture pesticide, and so on.


Product Detail

Product Tags

 Main features

  • The hopper could be washed easily without tools.
  • Servo motor drive screw.
  • Stainless steel structure, Contact parts SS304
  • Include handwheel of adjustable height.
  • Replacing the auger parts, it is suitable for material from super thin powder to granule.

Technical Specification

Model SPAF-H(2-8)-D(60-120) SPAF-H(2-4)-D(120-200) SPAF-H2-D(200-300)
Filler Quantity 2-8 2-4 2
Mouth Distance 60-120mm 120-200mm 200-300mm
Packing Weight 0.5-30g 1-200g 10-2000g
Packing Weight 0.5-5g,<±3-5%;5-30g, <±2% 1-10g,<±3-5%;10-100g, <±2%;100-200g, <±1%; <100g,<±2%;100 ~ 500g, <±1%;>500g, <±0.5%
Filling speed 30-50 times/min./filler 30-50 times/min./filler 30-50 times/min./filler
Power supply 3P, AC208-415V, 50/60Hz 3P  AC208-415V  50/60Hz 3P, AC208-415V, 50/60Hz
Total Power 1-6.75kw 1.9-6.75kw 1.9-7.5kw
Total Weight 120-500kg 150-500kg 350-500kg
