Expansion Wedge anchor carbon steel for concrete
Specification
| Product name | wedge anchor/through bolt |
| Surface | Plain, Zinc plated, black , HDG |
| System ofMeasurement | Metric |
| Place of Origin | Yongnian, Hebei, China |
| Brand Name | TYB |
| Material | Carbon steel Q235 |
| Diameter | M6, M8, M10, M12, M14, M16, M20,M24 |
| Length | 40-400mm |
| Standard | DIN,ANSI,ISO,GB |
| Certificate | ISO9001:2008 |
| Grade | 4.8 |
| Packing | Box+Carton+pallet |
| MOQ | 1,000pcs |
| Productive Process | wire rod→Anneal→Acid cleaing→Draw wire→molding and rolling thread→Heat treatment→Surface treat →Packing |
| Quality Control | Raw material inspect→process monitoring→Product test→Packaging check |
| Application | Wind tower,Nuclear power,Railway,Automotive industry,Construction,Electronic industry |
| Port | Tianjin,Qingdao, Customized |
| Payment Terms | T/T,FOB,CIF, |
| Sample | Available |
Product details
How to use it
| Anchor Size | Thread Length | Min.Embedment | Max.FaxThickness | WeightKgs/1000 | Pull outLoad kds |
| M6*40 | 18 | 27 | 3 | 10.3 |
850 |
| M6*55 | 25 | 35 | 15 | 12.7 | |
| M6*70 | 25 | 35 | 30 | 15.0 | |
| M6*95 | 25 | 35 | 55 | 16.7 | |
| M8*50 | 25 | 35 | 10 | 22.5 |
1150 |
| M8*65 | 25 | 40 | 20 | 26.4 | |
| M8*80 | 25 | 40 | 35 | 31 | |
| M8*95 | 25 | 40 | 50 | 35 | |
| M8*105 | 25 | 40 | 60 | 38.3 | |
| M8*120 | 25 | 40 | 75 | 43.6 | |
| M10*85 | 30 | 40 | 15 | 54.0 | 1500 |
| M10*90 | 30 | 50 | 20 | 55.6 | |
| M10*95 | 30 | 50 | 35 | 58.3 | |
| M10*115 | 30 | 50 | 55 | 67 | |
| M10*120 | 30 | 50 | 60 | 70.5 | |
| M10*130 | 30 | 50 | 70 | 75 | |
| M12*80 | 40 | 50 | 20 | 76 | 2300 |
| M12*100 | 40 | 60 | 30 | 88 | |
| M12*120 | 40 | 60 | 50 | 120 | |
| M12*135 | 40 | 60 | 65 | 112.5 | |
| M12*150 | 40 | 60 | 80 | 133 | |
| M16*105 | 60 | 70 | 15 | 170.5 | 3400 |
| M16*140 | 60 | 80 | 40 | 219 | |
| M20*125 | 65 | 85 | 15 | 321.5 | 5400 |
| M20*160 | 65 | 100 | 40 | 387 | |
| M20*200 | 65 | 100 | 80 | 469 |
Note
1. The above parameter is only for reference, the product is subject to the actual dimension.
2.Customized product is welcome, please contact us for more details.
FAQ
Q:How can I get a quotation?
A:Kindly provide us your details request (item No, style, logo, size, material, surface treatment, quantity etc.) the more detailed the better, leave us an inquiry or email to us and we will response promptly!
Q:What’s the process of order?
A:Send us Inquiry →get quotation →payment done →open mold and make samples→deliver you samples or send you pictures of samples for approval→mass production.
Q:When can l expect the customized product to be finished?
A:Sample:7-10 working days (Standard).
Bulk order:20-25 working days(Standard).
