China Extra long hand pallet jacks Series Manufacturer and Supplier | TCT

Extra long hand pallet jacks Series

Short Description:

Loading capacity: 2000kg Max fork height: 190/ 200mm Min fork height: 75/85mm Fork length: 1500/1800mm Fork overall width: 550/685mm


Product Detail

Product Tags

Extra long pallet jack is suit for different applications, including horizontal transport, order picking, loading / unloading and stacking,feature a robust draulic pump design, cast in one piece to keep oil in the pump and off your floor.With configurations available to suit a wide range of applications.

W Choose the ZM20L Extra long hand Pallet truck?

● High-quality one piece integrated pump

● Strong torsion-resistant steel construction and reinforcement under pallet truck forks

● Available in 1500/1800mm long as standard,other special size are available on request.

● Easy access entry and exit rollers,nylon,pu,rubber wheels for your choose

● Ergonomic handle

● Easy to use release lever

● Powered coating painting,normal red,yellow and other special colors customization is acceptable.

● Best after-sale service,1 year complete hand pallet truck warranty and 2 years free spare parts provide.

● Original Chinese hand pallet jack manufacturer with good quality

ZM20L Extra long hand pallet jacks is designed to suit extra deeper and oversize  pallets with 3.5mm thickness steel plate ,the strong steel construction is unbeatable. With robot welding and hand welding double check ,we ensure that all critical stress points are reinforced, ensuring longevity and reliability. Using best draulic unit,one piece casting pump and good quality seals ensure less oil leak problem on our pallet truck.

The ZM20L extra long Pallet Jack is an outstanding choice for any warehouse, loading bay or workplace.Using the ergonomic rubber handle, and high-quality rollers, it make maneuverability and highly rotating steer and load wheels make tight spaces so simple.

Considering different customers operating frequency and environment,we provide long after sale time,1 year complete hand pallet truck warranty and 2 years free spare parts provide.

There’s  ZM20L extra long pallet jack series,designed to keep you move quick,move easy!

Product Specifications

Descriptiom/Model No.   ZM20L
Pump type     Intergrated pump
Standard Power Type   Manual
Rated Capacity kg 2000
Wheels Wheel Type-Front/Rear   Nylon/Pu/Rubber
Front Wheel mm 80*70
Drive wheel mm 180*50
Dimension Mini lift height mm 75/85
Max lift height mm 190/200
Fork width mm 685/550
Fork length mm 1500/1800
