China FTTH 8 port GEPON GPON OLT compatible with HUAWEI ZTE BDCOM ONU Manufacturer and Supplier

FTTH 8 port GEPON GPON OLT compatible with HUAWEI ZTE BDCOM ONU

Short Description:

It provides a 16 * downlink GPON port, 4 *GE combo port and 2* 10G SFP+ port for uplink. The height is only 1U for easy installation and space-saving.

Material: Steel shell

Size: 440mm×44mm×300mm(L*W*H)

Weight: ≤6.5kg

Send email to us Download as PDF

Product Detail

Product Tags

Product Overview:
GPON OLT 8PON is a small capacity and enhancement mode cassette GPON OLT,meeting the requirements of ITU-T G.984/G.988 and relative standards of China Telecom/Unicom GPON, possessing super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirement on account of its excellent management, maintenance and monitoring capability, abundant service features and flexible network mode. GPON OLT 8PON can be used with network management system so as to provide users with the perfect
solution. It provides 8*downlink GPON port, 4 *GE combo port,2*Alarm port and 2* 10G SFP+ port for uplink. The height is only 1U for easy installation and space saving. GPON OLT 8PON is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.

Product Specification:

Item	GPON OLT 8PON
Service Port	8PON port,4GE COMBO port, 2*10GE SFP+ port
Redundancy Design	Dual power supply Support AC input, double DC input and AC+DC input
Power Supply	AC: input 100~240V 50/60Hz; DC: input 36V~75V;
Power Consumption	≤90W
Dimensions (Width xHeight x Depth)	440mm×44mm×300mm
Weight (Full-Loaded)	≤6.5kg
Environmental Requirements	Working temperature: -10°C~55°C Storage temperature: -40°C~70°C Relative humidity: 10%~90%, non-condensing
