Good Performance Refrigerator Bi-Metal Defrosting Thermostat 6615JB2003J
Description
| Product Name | Good Performance Refrigerator Bi-Metal Defrosting Thermostat 6615JB2003J |
| Use | Temperature control/Overheat protection |
| Reset type | Automatic |
| Base material | resist heat resin base |
| Electrical Ratings | 15A / 125VAC, 7.5A / 250VAC |
| Operating Temperature | -20°C~150°C |
| Tolerance | +/-5 C for open action(Optional +/-3 C or less) |
| Protection class | IP00 |
| Contact material | Silver |
| Dielectric Strength | AC 1500V for 1 minute or AC 1800V for 1 second |
| Insulation Resistance | More than 100MW at DC 500V by Mega Ohm tester |
| Resistance Between Terminals | Less than 100mW |
| Diameter of bimetal disc | 12.8mm(1/2″) |
| Approvals | UL/ TUV/ VDE/ CQC |
| Terminal type | Customized |
| Cover/Bracket | Customized |
Applications
Typical Applications:
- Automotive seat heaters
- Water heaters
- Electric heaters
- Anti freeze sensors
- Blanket heaters
- Medical applications
- Electrical appliance
- Ice makers
-Defrost heaters
- Refrigerated
-Display cases
Features
• Various terminal and lead wires options
• Standard +/5°C tolerance or optional +/-3°C
• Temperature range -20°C to 150°C
• Very economical applications
• Low profile
• Narrow differential
• Dual contacts for extra reliability
• Automatic reset
• Electrically insulated case
Craft Advantage
Slimmest construction
Dual contacts structure
High reliability for contact resistance
Safety design according to IEC standard
Environmental friendly towards RoHS,REACH
Automatic resettable
Accurate and quick switching snap action
Available horizontal terminal direction
Feature Advantage
Wide variety of installation fixtures and probes are available to suit customer needs.
Small size and fast response.
Long-term stability and reliability
Excellent tolerance and inter changeability
Lead wires can be terminated with customer-specified terminals or connectors
