-LC-8M Professional Live Cast Casting Video Live Cast Station

Short Description:

1. Video processing: hardware switching station, hardware signal (SDI, HDMI, DVI, VGA) + NDI +Stream+ DDR file, mixed switching;2, Audio processing: digital mixer + analog mixer + audio hardware delay device;3, Recording: HD video MPEg2-HL + MP4 + Built-in hardware recording unit (backup);4. Live broadcast: Http, Rtmp;5. Audio and video hardware delay broadcast system;6. Guide calls and TALLY;7. Captioning system, slow motion system, virtual keying system, audio and video editing system;8. Automatic switching;9. Application: studio, education recording, media live broadcast, all kinds of meetings and activities live broadcast;10. Size: 380mm×410mm×170mm;  Weight: about 10kg;


Product Detail

Product Tags

1 – 4 Pieces

$9090.00
Click to order -LC-8M on Alibaba



5 – 29 Pieces

$8333.00
Click to order -LC-8M on Alibaba



>=30 Pieces

$7575.00
Click to order -LC-8M on Alibaba



Product specification sheet

Model Number -LC-8M
Power supply AC110V-240V,50Hz,400W
Operating temperature 0-40℃
Size (L×W×H)410mm×370mm×160mm
Weight 10kg
Video output PGM output DVI×1,HDMI×1,SDI×1,NDI×1;PVW output DVI×1,HDMI×1,SDI×1;Systems display HDMI×1
Audio input Stereo (L,R) IN RCA×5,MIC XLR×5
Audio output Stereo (L,R) OUT RCA×1,Balanced XLR OUT×2,Monitor3.5×1,Playback monitor3.5×1,The director calls MIC3.5×2
Other interface USB2.0×2,USB3.0×2,RJ451000M×1
Sound console Digital mixer×5, Analog mixer×5,Audio hardware delay device×1
Recording High definition video MPEG2-HL, Streaming media MP4
live streaming http,rtmp
Delay broadcast Audio and Video hardware delay broadcasting system; (Non – Standard)
subtitle CG-Alpha DVE, Video playback ,Virtual matting system
configuration Intel i9 9900TCPU, RAM 16G, 1TB SSD
Systerm Windows 10

Product description

1. Hardware:  i9  9900T CPU, more than 16 GB memory, gigabit NIC, more than 1TB SSD disk, four built-in HD display,  There is one main system screen of 17.3 inches or more, one hardware switching output monitoring screen of 6.5 inches or more, two signal input monitoring screens of 4.3 inches or more, and four screens are all 1920×1080LED HD screens. It is a portable all-in-one machine for purchasing, broadcasting, recording and broadcasting of mg alloy with built-in 8-channel HD acquisition and coding system.

2. Input: VGA×2, DVI×8, HDMI×8, SDI×8, NDI×6, Stream×8, output: DVI, HDMI, SDI, NDI, NDI, broadcast output: SDI×2, loop out:  SDI×8, HDMI home screen output, component VGADVIHDMI external subtitle machine input interface and key, output includes hardware PGM output and PVW output;

3. Built-in six channel hardware hd mixed stunt platform, full interface mixed input hardware mixed stunt switch, built-in picture-in-picture any position rocker potentiometer, built-in broadcast damping switch T push rod, achieve zero second full frame hard cutting, hardware mixed 1920×1080, coding resolution 1920×1080,  Full HD 4:4:4 hardware lossless switching at the same time can also realize the input signal and local material DDR (pictures, videos, PPT, etc.) file switching, hardware rotary encoder control DDR pause, forward and backward select player point and control playback, 100 kinds of hardware switching special effects;

4. Hardware input signal and NDI, local files (video, picture, PPT) and network flow (mobile phone Stream, uav Stream and other RTMP Stream) real-time switch, built-in NDI×6, Stream×6, support push Stream and pull Stream mode.

5. Built-in digital + analog mixer, audio embedded and unembedded, realize the mixing of digital audio and analog audio, provide SDI×5, HDMI×5 digital audio embedded/unembedded input selection hardware switch ×5, and digital audio ×5, analog stereo ×5, MAC XLR×5 and other external input audio mixing,  Modulated audio can be embedded for HDMI, SDI output, at the same time can be separated into stereo output, built-in 48V phantom power supply, XLR×5 input, stereo ×5 input, stereo ×1 output, broadcast monitoring 3.5×1, broadcast monitoring 3.5×1, broadcast monitoring 3.5×1, guide talk headset  3.5×1;

6. Built-in hardware audio delay device, through the hardware knob to adjust the speed of audio, audio and video accurate synchronization;

7. Built-in broadcast-level hardware recording unit, recording format is FHD broadcast-level constant frame constant code MP4 file, and according to the time of automatic segmental recording, ensure the recording safety;

8. built-in hardware rocker potentiometer, control 4 sets of camera push, pull, shake, tilt, tilt;

9. Built-in hardware TALLY for the 4-channel multicast call system and 4-channel multicast prompt system;

10. Built-in hardware stepping encoder captioning control system, realize captioning selection and captioning switch;

11. Built-in hardware single key key keying system, hardware rotary encoder to adjust the virtual keying effect, virtual composite image can be used as a signal source to switch with other signals and files through t-type damping switch push rod;

12. Built-in audio and video digital hd hardware delay broadcast system, in the process of live broadcast director can deal with emergency

13. The delay switching and emergency switching of the hardware delay broadcasting system and the switching between the various signals of the guide station can achieve the frame synchronization and real-time full-frame hard cutting. The video has no compression hardware delay and 4GB independent hardware cache.

14. Software:  Built-in video coding system, can record MPEG2, AVI-DV25, AVI without compression, AVI hd, provide the original 4-bit simultaneous recording and multi-bit editing system, built-in streaming media WMV9, H.264 encoding system, built-in dual-bit stream recording and live broadcasting system,  Live recording of WMV, MP4 and broadcast-grade HD MPEg2-HL at 50Mbps/S, built-in WMS and FMS release system and provide FMS audio and picture synchronization adjustment;

15. Built-in CG-Alaph subtitle and online packaging system, realizing more than ten layers of Alaph dynamic subtitle, Angle mark and platform mark, etc. 3d objects and light effect, dynamic material, DVE direct video, video material and other ways to achieve an all-round visual packaging of live programming;

16. Built-in broadcast grade nonlinear editing system;

17. Interface: VIDEO IN×8 (BNC);  VGA IN×2;  DVI IN×8;  HDMI IN×8;  VIDEO OUT×8 ring OUT (BNC);  Stereo (LEFT, RIGHT) IN×5;  Professional microphone (48V) XLR IN×5;  Stereo (LEFT, RIGHT) OUT×1;  Balanced output XLR OUT×2;  DVI OUT×2;  HDMI OUT×2;  SDI IN×8;  SDI OUT (ring OUT)×8;  SDI OUT×2;  Main output monitoring 3.5×1;  Play monitoring 3.5×1;  MIC 3.5×2;  Network RJ45(1000 MB) ×1;  485 control RJ45×1;  USB2.0×2;  Usd 3.0×2;  PGM output HDMI×1, SDI×1, DVI×1;  PVW output HDMI×1, SDI×1, DVI×1;  Main output HDMI×1;  TALLY MINI XLR 6-core OUT×8;

18. WIN10 64-bit operating system;
