LNG Refueling Nozzle & Receptacle

Short Description:

Rotate the handle to connect vehicle receptacle. The check valve elements in both the refueling nozzle and the receptacle are forced to open with force from each other, in this way, the refueling route is open.


Product Detail

Product Tags

When the refueling nozzle is removed, valve elements in both the refueling nozzle and the receptacle will resume to its original position under the pressure of medium and spring, to make sure that complete seal in place and no leakage will occur. High performance energy storage seal technology; Safety lock structure;Patent vacuum insulation technology.

  • Product features
  • Specifications
  • Ask now

Product features

Three-jaw design (jaws can be opened forcibly), which can avoid spring freezing and effectively reduce the weight.

Specifications

Specifications

  • Name

    Refueling Nozzle

  • Model

    ALGC25G; T605-B

  • Max. fueling pressure

    1.6 MPa

  • Max. Working Pressure

    3.5 MPa

  • Fueling Flow

    190 L/min

  • Type of seal

    Spring energy storage seal ring

  • Interface size

    M36X2

  • Main Body Material

    304 stainless steel, aluminium alloy

  • Name

    Receptacle

  • Model

    T602

  • Max. fueling pressure

    1.6 MPa

  • Max. Working Pressure

    3.5 MPa

  • Fueling Flow

    190 L/min

  • Type of seal

    Spring energy, storage seal ring

  • Interface size

    M42X2

  • Main Body Material

    304 stainless steel
