MIMO screw mount antenna GPS GNSS+GSM 3G 4G LTE+WIFI combination antenna
MIMO GPS GNSS+GSM 3G 4G LTE+WIFI combination antenna is capable of GPS GNSS&GSM 3G 4G LTE&WIFI frequency. It is specially designed for customers who want an “all-in-one” antenna rather than having to install three separate antennas.
Detail
1.3 in 1 combination antenna
-ZH-3A is 3 in 1 combination antenna that can be mounted through an enclosure to provide connectivity to simple cellular telematics devices, such as those operating on LTE-M and NB-IoT.The 2G 3G 4G LTE antenna is quad band, so frequencies from 698 to 960Mhz and 1710 to 2700MHz are covered, allowing this antenna to be used worldwide for all cellular operators on 2G and 3G 4G networks.
The GPS/GNSS antenna has a wide-band from 1575.42MHz to 1602MHz to cover the 2 positioning satellite systems; GPS and GLONASS maximising the ability for an application to obtain a position fix and tracking data.
2. Waterproof and durable
This GSM 3G 4G LTE +WIFI +GPS Glonass combine antenna is designed to be extremely durable, vandal resistant, and IP67 weatherproof for operation in harsh environments.
Application
-ZH-3A is commonly used with applications such as automotive asset vehicle tracking, vending machines, telematics, energy metering and many more.
Product specification
|
Antenna Type |
All-in-one combined antenna |
|
Model Number |
-ZH-3A |
|
Frequency Range-MHz |
GPS GLONASS 1575.42-1602MHz GSM 3G 4G LTE 698-960MHz/1710-2170MHz/2300-2700MHz WIFI 2400-2500MHz |
|
GPS GLONASS Gain-DBi |
28DBI(LNA) |
|
GSM 3G 4G LTE WIFI Gain |
5DBI |
|
V.S.W.R |
≤1.8 |
|
Nominal Impedance-Ω |
50ohms |
|
Polarization |
Vertical |
|
Maximum Power-W |
50W |
|
Dimensions-mm |
81*15 or 46*15(two size available) |
|
Installation method |
Screw mounting,adhesive and L bracket mounting method |
|
Cable type |
RG174 cable |
|
Cable length |
3 Meter(Can be Longer or Shorter) |
|
Connector |
SMA male connector(other connector available) |
|
Operating Temperature |
-40℃~+80℃ |
|
Storage Temperature |
-40℃~+85℃ |
|
Compliant |
ROHS, CE, ISO |
