China Outdoor CPE AP 150Mbps 2.4G 500M Wifi Range Long distance Manufacturer and Supplier | TCT

Outdoor CPE AP 150Mbps 2.4G 500M Wifi Range Long distance

Short Description:


Product Detail

Product Tags

Feature

  •  Apply IEEE802.11b/802.11g/802.11n/802.3/802.3u
  • Transmitted power 802.11b 19dBm±2dBm802.11g 15dBm±2dBm802.11n 13dBm±2dBm
  • 2 Port 10/100Mbps Ethernet port,supportAuto MDI/MDIX
  • Support RESET
  • Many kinds of way to protect your data transmission
Hardware

Main chipset

AR9331

RAM

DDR2 64MB MAX DDR2 128MB

FLASH

SPI 8MBMAX 16MB

Protocol

IEEE802.11b/802.11g/802.11n/802.3/802.3u

Wireless rate

2.4g 150Mbps

Work frequency

2.4GHZ

Antennas

1* Directional antenna

Port

2*10/100M Ethernet port, support Auto MDI/MDIX

LED

Power, 1WAN, 1LAN, four signal led lights

Button

1*Reset

Power adapter

Non-standard POE 15V/1A

Max Power consumption

< 5W

SizeL*W*H&Color

Size:141*85*26MMColor:Plastic white
Others

Work Environments

Operating Temperature0~ 40
Storage Temperature-40~ 70Operating Humidity10%~90% non-condensing
Storage Humidity10%~90% non-condensing
