P series (IP50) push pull connector plastic circular IP50 indoor used with very low cost
Product detail
Plastic P series products were originally developed specifically for the medical industry, and all of its product performance standards are in line with medical standards, including non-toxicity, high temperature sterilization, quick plug-in characteristics, light weight, low cost, compliance with ROHs, REACH, etc. Features. Because of these advantages, many industries are increasingly favoring this product, including industrial, test, consumer electronics, and more.
The product structure of the P series is simple and can be installed from inside and outside, ranging from 2 cores to 26 cores. The PC or PSU material shell can make the product very light and not easy to crack. The plugging life can reach at least 2000 times. Can withstand more than 200 times of high temperature steam sterilization and alcohol sterilization, corrosion resistance. The push-pull self-locking structure design can achieve quick operation in actual use, and separate the plug from the socket in an emergency. The tail of the plug can be made of different colors of injection molding material, which can make each plug easy to identify, or it can be sheathed without injection molding. P series products have a total of 4 different positioning, which can prevent mis-plugging. In addition, we have developed a disposable plug. This plug is not strictly locked. The pulling force of about 20N can separate the plug from the socket. Its cost is lower, so it is suitable for one-time use and can be discarded. Type plugs can be made in different colors.
Features
- Contact number: 2~26
- Size:1,2,3,4(Hole size from 14.1 to 20.1mm)
- High density
- Mating cycles >2000
- >72Hours salt spray corrosion test
- Solder/PCB/Crimp terminal available
- Shell material: PC or PSU
- Contact material: brass gold plated
- Insulator: PPS/PEEK
- Temperature range:-55 ~ 250℃
- IP50 protection
- ４ kinds of coding。
Applications
P series products have many applications in adult monitors, ventilators, fetal monitoring, portable medical equipment, and consumer electronics.
First of all, the exquisite appearance design of the P series products is in line with the design concept of these high-end products, and also in line with the high quality requirements of these products. At the same time, the cost of the P series can be used in some products that are not very profitable. For products that require weight, I prefer to choose the P series because it is very lightweight. P series products, especially in the medical industry, have become a standard series of products after years of customer selection and development.
Indoor patient monitor
Portable Patient Monitor
portable diagnostic instrument
high-end consumer electronics
Product Parameter
| Shell material | PC or PSU | Lock style | Push pull/Breakaway |
| Socket material | Brass gold plated | Shell size | 1,2,3 |
| Pin material | Brass gold plated | Contact number | 2~26 |
| Insulator | PPS or PEEK | Termination area | AWG32~AWG16 |
| Shell color | Black, Grey | Termination style | Solder/PCB/Crimp |
| Mating cycles | >2000 | Produce technology | Turned |
| Pin diameter | 0.5~2.0 mm | Coding number | 3 |
| Temperature range | ℃(-55~125) | Cable diameter | 2.7~10.5mm |
| Testing voltage | 0.5~1.9(KV) | Overmoulding available | Yes |
| Current Rated | 3~20(A) | Salt spray corrosion test | 72 Hours |
| Humidity | 95% to 60℃ | Expiration date | 5 years |
| Resistance to vibration | １５ｇ（１０～２０００Ｈｚ） | Guarantee period | 12 months |
| Shielding efficiency | N/A | Certifications | Rohs/Reach/ISO9001/ISO13485/SGS |
| N/A | Aplication | Medical,testing,Equipment,Communiations | |
| Climatical category | 55/175/21 | Where used | Indoor |
| Shock resistance | ６ｍｓ，１００ｇ | Customized service | Yes |
| Protection index | IP50 | Sample available | Yes |
If you need more detail information, please download the catalog of B series or contact us!
Samples/Structures/Detail
Note: Only a few models and their drawings are listed here, if you need more information, please go to the download center to download our product manual or contact us.
