Plastic Pall Rings Tower Packing
Product Description
Plastic Pall Ring is fabricated by quality PTFE resin molding (as per product specification), turning, milling, planning and fine processing.
In chemical engineering, PP Pall Rings Tower Packing may increase gas-liquid contact area and enable intensive mixing.Applicable to various separation, absorption and desorption units, normal and diminished pressure unit, synthetic ammonia decarbonization and desulfurization system.PTFE is widely used in chemical, fertilizer, caustic soda, petrochemical, electric power, pharmaceutical and other industries, with excellent corrosion resistance and high temperature resistance.
Basic Info
|
S.N |
Specification |
Capacity |
Packing number n/m3 |
Specific surface area (m2/m3) |
Void ratio |
|
mm |
Kg/m |
(%) |
|||
|
1 |
20×20×2 |
522 |
110000 |
267 |
92.8 |
|
2 |
25×25×2 |
450 |
56000 |
219 |
93.4 |
|
3 |
38×38×2.5/3 |
320/360 |
140000 |
165 |
94.6 |
|
4 |
50×50×2.5/3 |
260/300 |
6500 |
113.5 |
94.9 |
|
5 |
65×65×4/5 |
330/500 |
4600 |
84 |
94.8 |
|
6 |
76×76×4/5 |
270/330 |
1850 |
73 |
92 |
Product Features
1、High separation rate—High throughput, low resistance, high separation efficiency and operating flexibility
2、Low temperature resistant—5% elongation maintained even if temperature is down to -196℃
3、Corrosion resistant—Inert to most chemicals and solvents, resistant to acid, alkali, water and organic solvents
4、Weather resistant-The best aging life among plastics
5、Nonhazardous-Not toxic to biology
Application
In chemical engineering, PTFE pall ring can increase gas-liquid contact area and enable intensive mixing. Application: Applicable to separation, absorption and desorption units, normal and diminished pressure unit, synthetic ammonia decarbonization and desulfurization system.
FAQ
Q: How does your factory do regarding quality control?
A: Quality is priority. People always attach great importance to quality control from the very beginning to the end of the production.Every product will be fully assembled and carefully tested before it’s packed for shipment.
Q:Can your products be customized?
A: Yes, we have a professional team which has rich experience ,so we’ll try our best to satisfy your requirement.
