SMT PCB offline AOI machine

Short Description:

SMT PCB offline AOI machine can correctly understand the cause and content of bad, so as to improve the production efficiency.


Product Detail

Product Tags

SMT PCB offline AOI machine

Description

Function

Offline automatic AOI optical detection equipment is aoi after reflow oven and wave soldering after the floorboard of the aoi, is on the SMT PCB production line after SMT SMD parts, or after soldering, electrolytic capacitor polarity test function automatically detect components of SMT and soldering state, detect the PCB welding bad, in addition, provides various statistical data on the production engineering, can correctly understand the cause of the poor and content, thus improve the production efficiency.

Specification

Product name: SMT PCB offline AOI machine

PCB Thickness: 0.3-8.0mm(PCB bending:≤3mm)

PCB element height: Upper 50mm Lower 50mm

Drive equipment: Panasonic servo motor

Motion system: High precision screw + linear double guide rails

Positioning accuracy: ≤10μm

Moving speed: Max.700mm/sec

Power Supply: AC220V  50HZ 1800W

Environmental requirements: Temperature :2~45℃, relative humidity 25%-85%(frost free)

Dimensions: L875*W940*H1350mm

Weight: 600KG

Our Service

1. More Professional service in Packaging and printing products exporting field

2. Better manufacture ability

3. Various payment term to choose:T/T,Western Union,L/C,Paypal

4. High quality/Safe material/Competitive price

5. Small order available

6. Quickly response

7. More safe and fast transport

Related Product

Stencil Printer FP2636 SMT pick and place machine K1830 Reflow oven IN6 Reflow oven IN12

FAQ

Q1: What’s your tem of the delivery?

A: Our ordinary delivery term is FOB Xiamen. We also accept EXW, CFR, CIF, DDP, DDU etc. We’ll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.



Q2: Which shipping way can you provide?

A: We can provide shipping by sea, by air and by express.



Q3: What’s your after-sale service?

A: Our quality warranty period is one year. Any quality problem will be solved to customer satisfactions.
