Stainless Steel High Lead Rolled Ground Ball Screw

Short Description:

The major differences between a rolled and ground ball screw are the manufacturing process, the lead error definition and geometrical tolerances. rolled ballscrews are made through a rolling process of the screw spindle instead of a grinding process. Rolled ball screws provide smooth movement and low friction which can be supplied quickly at a lower production cost.

Send email to us Download as PDF

Product Detail

Product Tags

Rolled Ball Screw Introduction And Selection Table

provide customized Rolled Ball Screws with flexible design and short delivery time. Customers can choose suitable products according to their actual situation.

Table of Shaft dia. and Lead combination for Rolled Ball Screw
		Lead (mm)
		0.5	1	1.5	2	2.5	3	4	5	6	8	10	12	15	20	30
Shaft dia (mm)	4		●		●
	5							●
	6		●		●					●		●
	8		●		●	●			●		●	●	●
	10				●		●	●	●	●		●	●	●	●
	12				●							●
	13												●	●	●
	14				●			●
	15								●			●			●
	16

Rolled Ball Screw Details

High Lead Miniature High Speed Rustproof Cold Rolled Ball Screw GSR

GSR series have three precision grades: JISC5/Ct7/Ct10. The axial clearance is provided according to the accuracy level: 0.005mm/0.02mm/0.05mm.

GSR series’s screw material S55C, nut material SCM415H and surface hardness of ball screw part is above HRC58.

Series List

PDF Catalogue

Stainless Steel Miniature High speed Cold Rolled Ball Screw BBS

BBS series have three precision grades: JISC5/Ct7/Ct10. The axial clearance is provided according to the accuracy level: 0.005mm/0.02mm/0.05mm.

BBS series’s screw material SUS440C, nut material SUS440 and surface hardness of ball screw part is above HRC55.

Series List

PDF Catalogue

Large-lead Integrated Type Precise Cold Rolled Ball Screw BSD

BSD series have two precision grades: JISC5/Ct7. The axial clearance is provided according to the accuracy level: 0.005mm/0.02mm. BSD series’s screw material SCM415, nut material SCM415 and surface hardness of ball screw part is above HRC58.

Series List

PDF Catalogue

High Lead Miniature High Speed Integrated Cold Rolling Ball Screw GT

GT series have two precision grades: JISC5/Ct7. The axial clearance is provided according to the accuracy level: 0.005mm/0.02mm. GT series’s screw material S55C, nut material SCM415H and surface hardness of ball screw part is above HRC58.

Series List

PDF Catalogue

Miniature Large Pitch Sleeve Type Single Nut Ball Screw TXR

Accuracy grade of TXR series（standard stock of sleeve type single nut ball screw）are based on C5、Ct7 and Ct10(JIS B 1192-3). According to accuracy grade, Axial play 0.005 (Preload ：C5), 0.02（Ct7） and 0.05mm or less（Ct10） are in stock. TXR series (Standard stock of Sleeve type single nut ball screw) of screw shaft screw material S55C (induction hardening), nut material SCM415H (carburizing and hardening), the surface hardness of the ball screw part is HRC58 or higher.

Series List

PDF Catalogue

Large Pitch High Speed Single Nut Ball Screw with M-thread GLR

Accuracy grade of GLR series (standard stock of single nut ball screw with metric thread) are based on C5、Ct7 and Ct10 (JIS B 1192-3). According to accuracy grade, axial play 0.005 (Preload ：C5), 0.02 (Ct7) and 0.05mm or less (Ct10) are in stock. GLR series (Standard stock of Single nut ball screw with metric thread) of screw shaft screw material S55C (induction hardening), nut material SCM415H (carburizing and hardening), the surface hardness of the ball screw part is HRC58 or higher.

Series List

PDF Catalogue
