Steel Wire Reinforced PU Pipe Production Line

Short Description:

Steel wire reinforced PU pipe production line has the features as easy operation, stable performance, continuous production etc.

This kind of pipe is widely used in industrial, agriculture, water conservancy, fishing, architecture, food industry, health, petroleum chemical etc which is the best choice for high pressure, sucking, oil/water/particle convey. It can perfectly replace the PVC, rubber and metal pipe. Factory, irrigation, coal mine, oil tank, wine factory, liquid food and sand blasting facility related application also works.

Send email to us Download as PDF

Product Detail

Product Tags

Features

1.Light weight, soft, good flexibility, anti corrosion, drolysis resistance, high transparent, nontoxic, tasteless, small turning radius and good negative pressure resistance.

2.Softness in extremely low temperature

3.Supreme long working life.

4.Pipe Classification: Steel Wire Reinforced PU Spiral Hose.

5.Conveying Medium: Chemical Liquid, Food and Drink, Oil, Water, Gas

6.Applicable Temperature for Solid Particles: -35℃—90℃

7.Hardness: 75a—98a

Main Technical Parameters

Extruder	SJ45/33,SJ55/33,SJ65/33
Pipe Size Range (mm)	￠25 — ￠500
Production Capacity (KG/H)	20 — 200

Pipe Specification Available

I.D.	O.D.	Operating limit		Bending radius( hose center)	Weight
I.D.	O.D.	Max Positive Pressure	Min Negative Pressure	Bending radius( hose center)	Weight
mm	mm	bar	bar	mm	KG/M
25	32	2,69	0,495	35	0,2
30	38	2,26	0,475	42	0,26
32	40	2,12	0,46	44	0,28
35	43	1,94	0,44	47	0,3
38	46	1,795	0,43	51	0,32
40	48	1,71	0,42	53	0,34
45	53	1,525	0,385	58	0,38
50	58	1,37	0,365	64	0,41
55	63	1,255	0,33	69	0,45
60	68	1,15	0,285	75	0,49
65	73	1,06	0,255	80	0,53
70	79	0,99	0,21	87	0,59
75	84	0,92	0,195	92	0,64
80	89	0,86	0,175	98	0,68
90	99	0,77	0,155	109	0,75
100	109	0,69	0,12	120	0,97
102	111	0,68	0,12	122	0,99
110	119	0,63	0,11	131	1,06
115	124	0,605	0,105	136	1,11
120	129	0,58	0,105	142	1,16
125	134	0,56	0,085	147	1,2
127	136	0,545	0,085	148	1,22
130	139	0,535	0,085	153	1,25
140	149	0,495	0,085	164	1,34
150	159	0,46	0,075	175	1,52
160	169	0,435	0,065	186	1,61
170	179	0,41	0,065	195	1,71
175	184	0,4	0,055	202	1,76
180	189	0,385	0,055	208	1,81
200	209	0,35	0,055	230	2
203	212	0,345	0,055	233	2,03
225	234	0,31	0,04	257	2,16
250	259	0,28	0,02	285	2,39
275	284	0,255	0,02	312	2,63
280	289	0,25	0,02	318	2,67
300	309	0,23	0,02	340	2,86
315	324	0,22	0,02	356	3
320	329	0,215	0,02	362	3,05
325	334	0,215	0,015	367	3,1
350	359	0,2	0,015	395	3,33
375	384	0,185	0,01	424	3,9
400	409	0,17	0,01	450	4,27
450	459	0,155	0,01	508	4,8
500	509	0,14	0,01	565	5,33
