Super Lowest Price China Small Loaders Hydraulic Motor Danfoss Eaton White M+S Orbit Motor Gerotor Motor

Short Description:

Cycloidal gear motors convert hydraulic energy (pressure, oil flow) into mechanical energy (torque, speed). Cycloidal gear motors operate on the principle of an internal gear (rotor) rotating within a fixed external gear (stator). The internal gear transmits the torque generated by the application of pressure from hydraulic oil fed into moto which is then delivered via the motor’s output shaft. Cycloidal gear motors have high starting torque and constant output torque at wide speed range.

Send email to us Download as PDF

Product Detail

Product Tags

We have been committed to offering easy,time-saving and money-saving one-stop purchasing service of consumer for Super Lowest Price China Small Loaders Hydraulic Motor Danfoss Eaton White M+S Orbit Motor Gerotor Motor, We are keeping durable small business relationships with additional than 200 wholesalers in the USA, the UK, Germany and Canada. For anyone who is intrigued in any of our products, make sure you experience free to speak to us.
We have been committed to offering easy,time-saving and money-saving one-stop purchasing service of consumer for China Danfoss Omh 151h1003, China Hydraulic Motor, Cycloidal Motor, Hydraulic Orbit Motor, Orbit Motor, At present our sales network is growing continually, improving service quality to meet customer’s demand. If you are interested in any products , make sure you contact us at anytime. We are looking forward to forming successful business relationships with you in near future.

GENERAL INFORMATION

Cycloidal gear motors convert draulic energy (pressure, oil flow) into mechanical energy (torque, speed). Cycloidal gear motors operate on the principle of an internal gear (rotor) rotating within a fixed external gear (stator). The internal gear transmits the torque generated by the application of pressure from draulic oil fed into moto which is then delivered via the motor’s output shaft. Cycloidal gear motors have high starting torque and constant output torque at wide speed range.

DISTIBUTORVALVE

GR, GRS series motors have spool valve: the distributor valve has been integrated with the output shaft. The cardan shaft rotates distributor valve and transfers mechanical energy from gerotor set to output shaft. The valve has drodynamic bearings and has infinite life when load ratings are not exceeded.

GEAR WHEEL SET

There are two forms of gearwheel set:

Roll-gerotor set has teeth fitted with rollers. The rollers reduce local stress and the tangential reaction forces on the rotor reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures.

Roll-gerotor sets are recommended for operation with thin oil and for applications with continually reversing applications with continually reversing loads. GR, GRS series motors have roll-gerotor set.

APPLICATION

» Conveyors

» Feeding mechanism of robots and manipulators

» Metal working machines

» Textile machines

» Agricultural machines

» Food industries

» Grass cutting machinery etc.

OPTIONS

» Model-Spool valve, roll-gerotor

» Flange mount

» Motor with needle bearing

» Side and rear ports

» Shafts: straight, splined and tapered

» Shaft seal for high and low pressure

» Metric and BSPP ports

» Speed sensoring

» Other special features

GENERAL

Max.Displacement		cm3/rev	397
Max.Speed		RPM	970
Max.Torque		Nm	cont.:610	int.:690
Max.Output		KW	15
Max.Pressure Drop		Mpa	cont.:17.5	int.:20
Max.Oil Flow		lpm	75
Min.Speed		RPM	10
Pressure Fluid			Mineral based-HLP(DIN 51524) or HM(ISO 6743/4)
Temperature Range			-40 to 140
Optimal Viscosity Range	mm2/s		20 to 75
Filtration			ISO code 20/16 (Min.) (recommended fluid filtration of 25 microns) ISO 20/16

Specification data for GR series motor

Displacement(cm3/rev)		GR 50	GR 80	GR 100	GR 125	GR 160	GR 200	GR 250	GR 315	GR 400
Displacement(cm3/rev)		51,5	80,3	99,8	125,7	159,6	199,8	250,1	315,7	397
Max Speed	Cont.	775	750	600	475	375	300	240	190	0
Int.*		970	940	750	600	470	375	300	240	190
Max Torque	Cont.	100	200	240	300	390	385	390	360	380
Nm	Int.*	130	220	280	340	430	460	470	470	470
Nm	Peak**	170	270	320	370	460	560	600	610	610
Max Output	Cont.	7	12,5	13	12,5	11,5	9	8	5	4,8
Int.*		8,5	15	15	14,5	14	12	9,5	8	6,8
Max Pressure Drop	Cont.	14	17,5	17,5	17,5	17,5	14	11	8,5	6,5
Mpa	Int.*	17,5	20	20	20	20	17,5	14	11,5	9
Mpa	Peak**	22,5	22,5	22,5	22,5	22,5	22,5	20	15	11,5
Max Oil Flow	Cont.	40	60	60	60	60	60	60	60	60
Int.*		50	75	75	75	75	75	75	75	75
Max Inlet Pressure	Cont.	17,5	17,5	17,5	17,5	17,5	17,5	17,5	17,5	17,5
	Int.*	20	20	20	20	20	20	20	20	20
	Peak**	22,5	22,5	22,5	22,5	22,5	22,5	22,5	22,5	22,5
Max.Return Pressure with Drain Line	Cont.	17,5	17,5	17,5	17,5	17,5	17,5	17,5	17,5	17,5
	Int.*	20	20	20	20	20	20	20	20	20
	Peak**	22,5	22,5	22,5	22,5	22,5	22,5	22,5	22,5	22,5
Max.Starting Pressure with Unloaded Shaft		1	1	1	0,9	0,7	0,5	0,4	0,3	0,3
Min Starting Torque	At max.press. drop Cont.	80	150	200	250	320	330	310	315	315
At max.press.drop Int.*		100	170	230	280	370	400	480	580	500
Min.Speed		10	10	10	10	10	10	10	10	10
Weight(kg)	MR(F)	6,8	6,9	7,2	7,3	7,5	8	8,4	9,1	9,8
MRQ(N)		6,2	6,3	6,6	6,8	7,6	7,2	7,8	8,6	9,3
