Surface Temperature Measuring Platinum Resistance
Features
1. Temperature measuring element
The use of German Heraeus brand temperature measuring components for users to ensure the accuracy of use, extend the user’s life cycle.
2. Housing package
The special housing package makes it closely fit with the measured surface, and the temperature measurement effect is more ideal.
Application
The surface mount platinum resistance temperature sensor can be Used for all kinds of industrial pipe surface temperature measurement, all kinds of circular surface and plane temperature measurement, motor coil or stator temperature monitoring.
There are a lot of surface temperature measurement problems in actual industrial production. But the environmental conditions, the temperature sensor, and the surface being measured interact to form a complex system. Various influencing factors directly or indirectly affect the accuracy of surface temperature. Therefore, surface temperature measurement is a measurement that is often needed but difficult to perform.
If the temperature sensor with the usual shape (such as needle, ball, cylinder, etc.) is used, the measurement error will be caused by the thermal conduction of the sensor’s own shape interfering with the original temperature field. Therefore, a special surface thermometer should be used for the accurate measurement of surface temperature. In other words, a thermometer with a special surface temperature sensor should be used to accurately measure the surface temperature. Typically, dedicated surface temperature sensors are sheet-like shapes with extremely thin thickness.
Product Types Choosing
|
Temperature measuring element type
|
single PT100, single PT1000, double PT100, double PT1000, NTC thermistor, T thermocouple, K thermocouple, etc
|
|
Accuracy level |
2B ±0.6℃, B ±0.3℃, A ±0.15℃, AA ±0.1℃, NTC accuracy (±1%), T thermocouple (±0.5℃), K thermocouple (±1.5℃). |
|
Temperature range |
-70~600℃ |
|
Electrical definition |
two -line system; three -line system; four -line system |
|
Heat conduction material |
stainless steel or copper |
|
Installation method |
high temperature thermal conductivity adhesive or thread drilling fixed |
|
On-site temperature measurement requirements |
high temperature resistance/corrosion resistance/wear resistance/earthquake resistance/other requirements |
Product Structure Diagram
