Transformer Corrugated Fin Double Spot Welding Machine

Short Description:

The transformer corrugated fin double spot welding machine is a auxiliary machine for Corrugated Tank Fin Forming. This spot welding machine allows to insert a strip on each panel edge, and attach it to the panels through spot welding system at a fixed pitch in the flutes.High Precision of each panel length.Easy welding on tanks frame.


Download as PDF

Product Detail

Product Tags

  ZDL-1300 Spot Welding Machine（Double spot welding）

Main Technical Parameters
 Workpiece width 300~1300mm or customized
 Workpiece thickness   1.0~1.5mm
 Welding power source 380V  50HZ、three-phase
 Rated power 63KVA
 Maxi short-circuit Current   current 17000A
 Rated adding pressure   0.5MPa
 Rated air pressure 0.6MPa
 Cooling water flow rate 12L/min

ZDL-1300 Spot welding machine（Double spot welding）Key Components

Sr

PARTS NAME

BRAND

1

  Electrical components Schneider

2

  PLC, touch screen, frequency converter, servo Mitsubishi or Siemens

3

  Reducer  Hangzhou jiacheng

4

  Bearing  Shanghai bearing co., LTD

5

  Planetary gear reducer  Hubei planetary

6

  Motor ABB or Siemens

7

  Ball screw, linear guide rail  THK

8

  Pneumatic components  AIRTAC

9

  Relay：  OMRON

10

  Welding electrode head：  Mitsubishi

11

  Cycloidal pin wheel speed reducer：  China’s Taixing
