Tungsten Carbide Roll Ring
Description
Tungsten Carbide Roll Ring are used for a variety of steel products, including high-speed wire rods, coils, rebars, steel pipes, and profiles.
Features
• 100% virgin tungsten carbide materials
• Excellent wear resistance & Impact resistance
• Corrosion resistance & Thermal fatigue toughness
• Competitive prices & Long life service
Cemented Carbide Plain Rollers
Tungsten Carbide Threaded Roll
3-Dimensional Tungsten Carbide Roller
GRADE OF TC ROLL RING
| Grade | Composition | Hardness
(HRA) |
Density
(g/cm3) |
T.R.S
(N/mm2) |
|
| Co+Ni+Cr% | WC% | ||||
| YGR20 | 10 | 90.0 | 87.2 | 14.49 | 2730 |
| YGR25 | 12.5 | 87.5 | 85.6 | 14.21 | 2850 |
| YGR30 | 15 | 85.0 | 84.4 | 14.03 | 2700 |
| YGR40 | 18 | 82.0 | 83.3 | 13.73 | 2640 |
| YGR45 | 20 | 80.0 | 83.3 | 13.73 | 2640 |
| YGR55 | 25 | 75.0 | 79.8 | 23.02 | 2550 |
| YGR60 | 30 | 70.0 | 79.2 | 12.68 | 2480 |
| YGH10 | 8 | 92.0 | 87.5 | 14.47 | 2800 |
| YGH20 | 10 | 90.0 | 87 | 14.47 | 2800 |
| YGH25 | 12 | 88.0 | 86 | 14.25 | 2700 |
| YGH30 | 15 | 85 | 84.9 | 14.02 | 2700 |
| YGH40 | 18 | 82 | 83.8 | 13.73 | 2850 |
| YGH45 | 20 | 80 | 83 | 13.54 | 2700 |
| YGH55 | 26 | 74 | 81.5 | 13.05 | 2530 |
| YGH60 | 30 | 70 | 81 | 12.71 | 2630 |
