TUV EN50618 H1Z2Z2-K & IEC62930 Solar DC Wire Cable

Short Description:

“Small cable, greater impotant”. When you select solar cables for your PV project, it is important to calculate the right cross section with the lowest power losses.Jiukai cable have 15 years of production experience in power cable. Our cables have TÜV TUV EN50618 H1Z2Z2-K & IEC62930 along with the highest manufacturing standards.

Send email to us Download as PDF

Product Detail

Product Tags

Product Introduction

The core solar cables of any diameter from 2.5mm² up to 16mm² are made in Shanhai,China. The standards of the cable covers single core and dual core. The layers of insulation are distinguished by color for improved and safer handling.

We supply only color-coded cables for safe and easy installation. The red cables are intended for use in positive (+) DC voltage and black cable are used for negative (-) DC voltage.

The cables are suitable for nominal DC voltage 1.5KV (Between conductor to conductor or conductor to earth) solar power systems.

● Halogen Free,Flame-resistant.

● 15 Years of Production Experience In Power Cable.

● TUV Approved & TUV 2PFG 1169/08.2007 PVI-F.

● Double Insulation Suitable for outdoor harsh environments.

● Stable connection & Reducing maintenance cost.

● Free Sample is available.

Specification Of Solar Cable

*TUV EN50618 H1Z2Z2-K & IEC62930 Solar cable 1 X mm² & 2X mm²*
	Conductor	Tinned fine Re copper strands,according to IEC60228.Class5
	Insulation	LSZH electron-beam cross-linked Polyolefin copolymer ROHS material, prior color black or as per customer’s request
	Sheath Jacket	LSZH & UV-resistant electron-beam cross-linked Polyolefin copolymer ROHS material, prior color black or as per customer’s request.
	Sheath color	Red/Black
	Nominal Voltage	UO/U 1.0/1.0 KV (AC) , 1.5/1.5kV (DC)
	Test voltage	No breakdown at 6.5 kV (AC) 50HZ 5min 20±5°C /15kV(DC) 5min 20±5°C
	Temperature Rating	Working Temperature —40C 〜+ 90 °C, Max conductor Temperature 125 °C (continuously 20h), Allowable short circuit temperature 200°C in 5 second
	Fire-resistant Performance	IEC 60332-1:2004
	Smoke Emission	IEC61034-1, min 60% luminousness;EN50268-2
	Halogen Conten	EN 50525-1:2011, Appendix B
	Low Fire Load	DIN 51900
	Executive Standard	EN 50618:2014
	Certification	TUV EN50618 H1Z2Z2-K & IEC62930

Low Losses In Every Part Of Your Solar System: The solar off grid or grid-tied system must be carefully designed with a target overall efficiency around 95%. To reach this target, we should not underestimate how important the selection of cables is.

Product Packaging

Product Parameters

Construction (Nxmm²)	Finished Cable OD(mm)	Max DC Resistance at 20 C (Q/KM)	Current (A)
Construction (Nxmm²)	Finished Cable OD(mm)	Max DC Resistance at 20 C (Q/KM)	Underground installation
1×2.5 mm²	5.05±0.2	8.21	39
1×4 mm²	5.55±0.3	5.09	52
1×6 mm²	6.15±0.3	3.39	67
1×10 mm²	7.4±0.3	1.95	93
1×16 mm²	8.72±0.3	1.25	125
2×2.5 mm²	5.55±0.3×11.6±0.5	8.21	39
2×4 mm²	5.05±0.3×10.5±0.5	5.09	52
2×6 mm²	6.15±0.3×12.9±0.6	3.39	67
2×10 mm²	7.4±0.3×15.4±0.8	1.95	93
2×16 mm²	8.72±0.3×18.1±0.8	1.25	125
